Audi specifications

Audi A5 Sportback specifications and photos

Audi A5 Sportback specifications are shown with trim options, key technical data, and a model photo gallery. Compare 8 configurations by engine size, power, seating, and transmission. The gallery includes 19 photos for visual reference.

Years 2019
Body type liftback
Trims 8
Photos 19
Interior of Audi A5 Sportback 2019
Overview

Audi A5 Sportback at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Audi A5 Sportback page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 163-286 hp and 1968-2967 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 163-286 hp
  • Engine displacement: 1968-2967 cc
  • Transmissions: 7, 8
  • Seating: 5 seats
Research hub

Photos, trims and specifications for Audi A5 Sportback

This model page brings gallery images, trim comparison, and detailed technical data together for the 2019 generation.

Open photo gallery 19 images Compare trims 8 configurations View detailed specs 1968-2967 cc Explore related pages Audi and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 163-286 hp
Engine displacement 1968-2967 cc
Seating 5 seats
Transmissions 7, 8
Trim / modification Engine Power Seats Transmission
40 TFSI 1984 cc 190 hp 5 7
45 TFSI quattro 1984 cc 245 hp 5 7
35 TDI 1968 cc 163 hp 5 7
40 TDI 1968 cc 190 hp 5 7
40 TDI quattro 1968 cc 190 hp 5 7
45 TDI quattro 2967 cc 231 hp 5 8
50 TDI quattro 2967 cc 286 hp 5 8
40 g-tron 1984 cc 170 hp 5 7

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

40 TFSI 45 TFSI quattro 35 TDI 40 TDI 40 TDI quattro 45 TDI quattro 50 TDI quattro 40 g-tron
40 TFSI 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 320
RPM at max torque 1450-4200
Engine 2.0 TSI
RPM at max power 4200-6000
Turbo +
Engine code EA888

Dimensions

Seats 5
Length mm 4757
Width 2029
Height mm 1386
Wheelbase mm 2824
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1595
Trunk capacity, L 465
Fuel tank, l 54
Turning circle, m 11
Gross weight, kg 2125
Width (without mirrors) mm 1843

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.7
Fuel consumption (urban), l. 100 km 5.1
Fuel consumption (combined), l. 100 km 5.9
Acceleration (0-100 km/h), s 7.5
The maximum speed, km / h. 241
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
45 TFSI quattro 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 245
Torque, Nm 370
RPM at max torque 1600-4300
Engine 2.0 TFSI
RPM at max power 5000-6500
Turbo +
Engine code EA888

Dimensions

Seats 5
Length mm 4757
Width 2029
Height mm 1386
Wheelbase mm 2824
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1595
Trunk capacity, L 465
Fuel tank, l 54
Turning circle, m 11
Gross weight, kg 2125
Width (without mirrors) mm 1843

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.6
Fuel consumption (urban), l. 100 km 5.7
Fuel consumption (combined), l. 100 km 6.8
Acceleration (0-100 km/h), s 6
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
35 TDI 37 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 163
Torque, Nm 380
RPM at max torque 1500-2750
Engine 2.0 TDI
RPM at max power 3250-4200
Turbo +

Dimensions

Seats 5
Length mm 4757
Width 2029
Height mm 1386
Wheelbase mm 2824
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1595
Trunk capacity, L 465
Fuel tank, l 54
Turning circle, m 11
Gross weight, kg 2125
Width (without mirrors) mm 1843

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 4.5
Fuel consumption (urban), l. 100 km 3.9
Fuel consumption (combined), l. 100 km 4.1
Acceleration (0-100 km/h), s 8.4
The maximum speed, km / h. 226
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
40 TDI 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 400
RPM at max torque 1900-3300
Engine 2.0 TDI
Compression 15.8
RPM at max power 3500-4000
Turbo +
Engine code DETA/DFHA (EA288)

Dimensions

Seats 5
Length mm 4757
Width 2029
Height mm 1386
Wheelbase mm 2824
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1595
Trunk capacity, L 465
Fuel tank, l 54
Turning circle, m 11
Gross weight, kg 2125
Width (without mirrors) mm 1843

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.1
Fuel consumption (urban), l. 100 km 4.2
Fuel consumption (combined), l. 100 km 4.5
Acceleration (0-100 km/h), s 7.9
The maximum speed, km / h. 241
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
40 TDI quattro 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 400
RPM at max torque 1900-3300
Engine 2.0 TDI
Compression 15.8
RPM at max power 3500-4000
Turbo +
Engine code DETA/DFHA (EA288)

Dimensions

Seats 5
Length mm 4757
Width 2029
Height mm 1386
Wheelbase mm 2824
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1595
Trunk capacity, L 465
Fuel tank, l 54
Turning circle, m 11
Gross weight, kg 2125
Width (without mirrors) mm 1843

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.9
Fuel consumption (urban), l. 100 km 4.8
Fuel consumption (combined), l. 100 km 5.2
Acceleration (0-100 km/h), s 7.6
The maximum speed, km / h. 235
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
45 TDI quattro 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2967
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 231
Torque, Nm 500
RPM at max torque 1750-3250
Engine 3.0 TDI
RPM at max power 3250-4750
Turbo +
Engine code DHXC/DEND (EA897)

Dimensions

Seats 5
Length mm 4757
Width 2029
Height mm 1386
Wheelbase mm 2824
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1595
Trunk capacity, L 465
Fuel tank, l 54
Turning circle, m 11
Gross weight, kg 2125
Width (without mirrors) mm 1843

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 6.8
Fuel consumption (urban), l. 100 km 4.6
Fuel consumption (combined), l. 100 km 5.4
Acceleration (0-100 km/h), s 6.1
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-Tiptronic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
50 TDI quattro 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2967
Cylinders location V-shaped
Number of cylinders 6
Valves 32
Power, hp 286
Torque, Nm 620
RPM at max torque 1500-3000
Engine 3.0 TDI
RPM at max power 3750-4000
Turbo +
Engine code DCPC (EA897)

Dimensions

Seats 5
Length mm 4757
Width 2029
Height mm 1386
Wheelbase mm 2824
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1595
Trunk capacity, L 465
Fuel tank, l 54
Turning circle, m 11
Gross weight, kg 2125
Width (without mirrors) mm 1843

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.2
Fuel consumption (urban), l. 100 km 5.4
Fuel consumption (combined), l. 100 km 6
Acceleration (0-100 km/h), s 5.3
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-Tiptronic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
40 g-tron 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gas
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 170
Torque, Nm 270
RPM at max torque 1650-4400
Engine 2.0 G-TFSI
RPM at max power 4450-6000
Turbo +
Engine code EA888

Dimensions

Seats 5
Length mm 4757
Width 2029
Height mm 1386
Wheelbase mm 2824
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1595
Trunk capacity, L 465
Fuel tank, l 54
Turning circle, m 11
Gross weight, kg 2125
Width (without mirrors) mm 1843

Performance and fuel consumption

Acceleration (0-100 km/h), s 8.4
The maximum speed, km / h. 224
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
FAQ

Audi A5 Sportback questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Audi A5 Sportback?

This page lists 8 trims for the Audi A5 Sportback, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Audi A5 Sportback?

The listed configurations show a power range of 163-286 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Audi A5 Sportback?

The available specification data shows engine displacement from 1968-2967 cc across the trims listed on this page.

Which transmissions are listed for the Audi A5 Sportback?

The transmission options currently shown for this model are: 7, 8. Open a trim section to see the full data for a specific configuration.

Are there photos for the Audi A5 Sportback?

Yes. The gallery includes 19 photos for the Audi A5 Sportback, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
