BMW 4 Series Coupe (G22) specifications and photos

BMW 4 Series Coupe (G22) specifications are shown with trim options, key technical data, and a model photo gallery. Compare 5 configurations by engine size, power, seating, and transmission. The gallery includes 30 photos for visual reference.

Years 2020
Body type coupe
Trims 5
Photos 30
BMW 4 Series Coupe (G22) 2020 photo
Overview

BMW 4 Series Coupe (G22) at a glance

Quick model context before comparing photos and trim-level specifications.

Use this BMW 4 Series Coupe (G22) page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 184-374 hp and 1995-2998 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 184-374 hp
  • Engine displacement: 1995-2998 cc
  • Transmissions: 8
  • Seating: 4 seats
Research hub

Photos, trims and specifications for BMW 4 Series Coupe (G22)

This model page brings gallery images, trim comparison, and detailed technical data together for the 2020 generation.

Open photo gallery 30 images Compare trims 5 configurations View detailed specs 1995-2998 cc Explore related pages BMW and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 184-374 hp
Engine displacement 1995-2998 cc
Seating 4 seats
Transmissions 8
Trim / modification Engine Power Seats Transmission
420i 1998 cc 184 hp 4 8
430i 1998 cc 258 hp 4 8
M440i xDrive. 2998 cc 374 hp 4 8
420d 1995 cc 190 hp 4 8
420d xDrive 1995 cc 190 hp 4 8

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

420i 430i M440i xDrive. 420d 420d xDrive
420i 40 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 184
Torque, Nm 300
RPM at max torque 1350-4250
Engine 2.0i
RPM at max power 5000-6500
Turbo +
Engine code B48A20

Dimensions

Seats 4
Length mm 4768
Width 2081
Height mm 1383
Wheelbase mm 2851
Front track, mm 1575
Rear track, mm 1611
Kerb weight, kg 1600
Trunk capacity, L 440
Fuel tank, l 59
Turning circle, m 11.4
Ground clearance, mm 127
Gross weight, kg 2015
Width (without mirrors) mm 1852

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.2
Fuel consumption (urban), l. 100 km 5
Fuel consumption (combined), l. 100 km 5.8
Acceleration (0-100 km/h), s 7.5
The maximum speed, km / h. 240
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-Steptronic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
430i 41 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 258
Torque, Nm 400
RPM at max torque 1550-4400
Engine 2.0i
Compression 10.2
RPM at max power 5000-6500
Turbo +
Engine code B48B20

Dimensions

Seats 4
Length mm 4768
Width 2081
Height mm 1383
Wheelbase mm 2851
Front track, mm 1575
Rear track, mm 1611
Kerb weight, kg 1600
Trunk capacity, L 440
Fuel tank, l 59
Turning circle, m 11.4
Ground clearance, mm 127
Gross weight, kg 2015
Width (without mirrors) mm 1852

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.7
Fuel consumption (urban), l. 100 km 5.3
Fuel consumption (combined), l. 100 km 6.1
Acceleration (0-100 km/h), s 5.8
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-Steptronic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
M440i xDrive. 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2998
Cylinders location In-line
Number of cylinders 6
Valves 24
Power, hp 374
Torque, Nm 500
RPM at max torque 1850-5000
Engine 3.0i
RPM at max power 5500-6500
Engine code B58B30TÜ1

Dimensions

Seats 4
Length mm 4768
Width 2081
Height mm 1383
Wheelbase mm 2851
Front track, mm 1575
Rear track, mm 1611
Kerb weight, kg 1600
Trunk capacity, L 440
Fuel tank, l 59
Turning circle, m 11.4
Ground clearance, mm 127
Gross weight, kg 2015
Width (without mirrors) mm 1852

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9
Fuel consumption (urban), l. 100 km 6
Fuel consumption (combined), l. 100 km 7.1
Acceleration (0-100 km/h), s 4.5
The maximum speed, km / h. 250

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-Steptronic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
420d 41 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1995
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 400
RPM at max torque 1750-2500
Engine 2.0d
Compression 16.5
RPM at max power 4000
Turbo +
Engine code B47D20

Dimensions

Seats 4
Length mm 4768
Width 2081
Height mm 1383
Wheelbase mm 2851
Front track, mm 1575
Rear track, mm 1611
Kerb weight, kg 1600
Trunk capacity, L 440
Fuel tank, l 59
Turning circle, m 11.4
Ground clearance, mm 127
Gross weight, kg 2015
Width (without mirrors) mm 1852

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 4.9
Fuel consumption (urban), l. 100 km 3.9
Fuel consumption (combined), l. 100 km 4.2
Acceleration (0-100 km/h), s 7.1
The maximum speed, km / h. 240
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-Steptronic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
420d xDrive 41 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1995
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 400
RPM at max torque 1750-2500
Engine 2.0d
Compression 16.5
RPM at max power 4000
Turbo +
Engine code B47D20

Dimensions

Seats 4
Length mm 4768
Width 2081
Height mm 1383
Wheelbase mm 2851
Front track, mm 1575
Rear track, mm 1611
Kerb weight, kg 1600
Trunk capacity, L 440
Fuel tank, l 59
Turning circle, m 11.4
Ground clearance, mm 127
Gross weight, kg 2015
Width (without mirrors) mm 1852

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.2
Fuel consumption (urban), l. 100 km 4.2
Fuel consumption (combined), l. 100 km 4.6
Acceleration (0-100 km/h), s 7.4
The maximum speed, km / h. 238
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-Steptronic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
FAQ

BMW 4 Series Coupe (G22) questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the BMW 4 Series Coupe (G22)?

This page lists 5 trims for the BMW 4 Series Coupe (G22), with key data shown in the comparison table and full specifications grouped below.

What is the power range for the BMW 4 Series Coupe (G22)?

The listed configurations show a power range of 184-374 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the BMW 4 Series Coupe (G22)?

The available specification data shows engine displacement from 1995-2998 cc across the trims listed on this page.

Which transmissions are listed for the BMW 4 Series Coupe (G22)?

The transmission options currently shown for this model are: 8. Open a trim section to see the full data for a specific configuration.

Are there photos for the BMW 4 Series Coupe (G22)?

Yes. The gallery includes 30 photos for the BMW 4 Series Coupe (G22), including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
