Cadillac specifications

Cadillac XTS specifications and photos

Cadillac XTS specifications are shown with trim options, key technical data, and a model photo gallery. Compare 6 configurations by engine size, power, seating, and transmission. The gallery includes 20 photos for visual reference.

Years 2016 - 2017
Body type sedan
Trims 6
Photos 20
Interior of Cadillac XTS 2016
Overview

Cadillac XTS at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Cadillac XTS page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 304-410 hp and 3564-3600 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 304-410 hp
  • Engine displacement: 3564-3600 cc
  • Transmissions: 6, 6-speed automatic
  • Seating: 5 seats
Research hub

Photos, trims and specifications for Cadillac XTS

This model page brings gallery images, trim comparison, and detailed technical data together for the 2016 generation.

Open photo gallery 20 images Compare trims 6 configurations View detailed specs 3564-3600 cc Explore related pages Cadillac and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 304-410 hp
Engine displacement 3564-3600 cc
Seating 5 seats
Transmissions 6, 6-speed automatic
Trim / modification Engine Power Seats Transmission
3.6 AT (304) 3564 cc 304 hp 5 6
3.6 AT AWD (304) 3564 cc 304 hp 5 6
3.6 AT AWD (410) 3600 cc 410 hp 5 6
3.6i (304 h.p.) 6-speed automatic 3564 cc 304 hp 5 6-speed automatic
3.6i (304 hp) 6-speed 4x4 automatic transmission 3564 cc 304 hp 5 6
3.6i (410 hp) 6-speed 4x4 3600 cc 410 hp 5 6

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

3.6 AT (304) 3.6 AT AWD (304) 3.6 AT AWD (410) 3.6i (304 h.p.) 6-speed automatic 3.6i (304 hp) 6-speed 4x4 automatic transmission 3.6i (410 hp) 6-speed 4x4
3.6 AT (304) 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3564
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 304
Torque, Nm 358
RPM at max torque 5200
Engine 3.6i
Compression 11.5.1
RPM at max power 6800
Engine code LFX

Dimensions

Seats 5
Length mm 5130
Width 1829
Height mm 1499
Wheelbase mm 2819
Front track, mm 1549
Rear track, mm 1575
Kerb weight, kg 1817
Trunk capacity, L 510
Fuel tank, l 70
Turning circle, m 11.8

Suspension

Type of front suspension Independent, such as MacPherson
Rear suspension Independent suspension with H-arms

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13
Fuel consumption (urban), l. 100 km 8.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6 AT AWD (304) 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3564
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 304
Torque, Nm 358
RPM at max torque 5200
Engine 3.6i
Compression 11.5.1
RPM at max power 6800
Engine code LFX

Dimensions

Seats 5
Length mm 5130
Width 1829
Height mm 1499
Wheelbase mm 2819
Front track, mm 1549
Rear track, mm 1575
Kerb weight, kg 1912
Trunk capacity, L 510
Fuel tank, l 70
Turning circle, m 11.8

Suspension

Type of front suspension Independent, such as MacPherson
Rear suspension Independent suspension with H-arms

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13.8
Fuel consumption (urban), l. 100 km 9

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6 AT AWD (410) 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3600
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 410
Torque, Nm 500
RPM at max torque 1900
Engine 3.6i
RPM at max power 6000
Turbo +
Engine code LF3

Dimensions

Seats 5
Length mm 5130
Width 1829
Height mm 1499
Wheelbase mm 2819
Front track, mm 1549
Rear track, mm 1575
Kerb weight, kg 1912
Trunk capacity, L 510
Fuel tank, l 70
Turning circle, m 11.8

Suspension

Type of front suspension Independent, such as MacPherson
Rear suspension Independent suspension with H-arms

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 14.7
Fuel consumption (urban), l. 100 km 10.2

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6i (304 h.p.) 6-speed automatic 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3564
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 304
Torque, Nm 358
RPM at max torque 5200
Engine 3.6i
Compression 11.5.1
RPM at max power 6800
Engine code LFX

Dimensions

Seats 5
Length mm 5130
Width 1829
Height mm 1499
Wheelbase mm 2819
Front track, mm 1549
Rear track, mm 1575
Trunk capacity, L 510
Fuel tank, l 70
Turning circle, m 11.8

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13
Fuel consumption (urban), l. 100 km 8.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6i (304 hp) 6-speed 4x4 automatic transmission 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3564
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 304
Torque, Nm 358
RPM at max torque 5200
Engine 3.6i
Compression 11.5.1
RPM at max power 6800
Engine code LFX

Dimensions

Seats 5
Length mm 5130
Width 1829
Height mm 1499
Wheelbase mm 2819
Front track, mm 1549
Rear track, mm 1575
Trunk capacity, L 510
Fuel tank, l 70
Turning circle, m 11.8

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13.8
Fuel consumption (urban), l. 100 km 9

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6i (410 hp) 6-speed 4x4 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3600
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 410
Torque, Nm 500
RPM at max torque 1900
Engine 3.6i
RPM at max power 6000
Turbo +
Engine code LF3

Dimensions

Seats 5
Length mm 5130
Width 1829
Height mm 1499
Wheelbase mm 2819
Front track, mm 1549
Rear track, mm 1575
Trunk capacity, L 510
Fuel tank, l 70
Turning circle, m 11.8

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 14.7
Fuel consumption (urban), l. 100 km 10.2

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
FAQ

Cadillac XTS questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Cadillac XTS?

This page lists 6 trims for the Cadillac XTS, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Cadillac XTS?

The listed configurations show a power range of 304-410 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Cadillac XTS?

The available specification data shows engine displacement from 3564-3600 cc across the trims listed on this page.

Which transmissions are listed for the Cadillac XTS?

The transmission options currently shown for this model are: 6, 6-speed automatic. Open a trim section to see the full data for a specific configuration.

Are there photos for the Cadillac XTS?

Yes. The gallery includes 20 photos for the Cadillac XTS, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
