Datsun redi-GO specifications and photos

Datsun redi-GO specifications are shown with trim options, key technical data, and a model photo gallery. Compare 3 configurations by engine size, power, seating, and transmission. The gallery includes 22 photos for visual reference.

Years 2016
Body type hatchback
Trims 3
Photos 22
Datsun redi-GO 2016 hatchback
Overview

Datsun redi-GO at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Datsun redi-GO page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 54-68 hp and 799-996 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 54-68 hp
  • Engine displacement: 799-996 cc
  • Transmissions: 5
  • Seating: 4-5 seats
Research hub

Photos, trims and specifications for Datsun redi-GO

This model page brings gallery images, trim comparison, and detailed technical data together for the 2016 generation.

Open photo gallery 22 images Compare trims 3 configurations View detailed specs 799-996 cc Explore related pages Datsun and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 54-68 hp
Engine displacement 799-996 cc
Seating 4-5 seats
Transmissions 5
Trim / modification Engine Power Seats Transmission
0.8 MT 799 cc 54 hp 4 5
0.8i (54 HP) 5-Mech 799 cc 54 hp 5 5
1.0 (68 h.p.) 5-mech 996 cc 68 hp 5 5

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

0.8 MT 0.8i (54 HP) 5-Mech 1.0 (68 h.p.) 5-mech
0.8 MT 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 799
Cylinders location In-line
Number of cylinders 3
Valves 12
Power, hp 54
Torque, Nm 72
RPM at max torque 4386
Engine 0.8i
RPM at max power 5678
Engine code F8D

Dimensions

Seats 4
Length mm 3429
Width 1560
Height mm 1541
Wheelbase mm 2348
Trunk capacity, L 222
Fuel tank, l 28
Turning circle, m 4.73
Ground clearance, mm 185

Suspension

Type of front suspension Independent
Rear suspension Torsion beam

Brake system

The front brakes Ventilated disc
Rear brakes Drum

Performance and fuel consumption

Fuel consumption (combined), l. 100 km 4
Acceleration (0-100 km/h), s 15.9
The maximum speed, km / h. 140

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission country of origin India

Equipment

Wheels

Disc diameter 13
Tires 155/80R13
0.8i (54 HP) 5-Mech 29 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 799
Cylinders location In-line
Number of cylinders 3
Valves 12
Power, hp 54
Torque, Nm 72
RPM at max torque 4386
Engine 0.8i
RPM at max power 5678
Engine code F8D

Dimensions

Seats 5
Length mm 3429
Width 1560
Height mm 1541
Wheelbase mm 2348
Trunk capacity, L 222
Fuel tank, l 28
Turning circle, m 9.6
Ground clearance, mm 185

Performance and fuel consumption

Fuel consumption (combined), l. 100 km 4
Acceleration (0-100 km/h), s 15.9
The maximum speed, km / h. 140

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission country of origin India
1.0 (68 h.p.) 5-mech 29 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 996
Cylinders location In-line
Number of cylinders 3
Valves 12
Power, hp 68
Torque, Nm 90
RPM at max torque 3400
Engine 1.0
Compression 11.0
RPM at max power 6000
Engine code K10B

Dimensions

Seats 5
Length mm 3429
Width 1560
Height mm 1541
Wheelbase mm 2348
Trunk capacity, L 222
Fuel tank, l 28
Turning circle, m 9.6
Ground clearance, mm 185

Performance and fuel consumption

Acceleration (0-100 km/h), s 15
The maximum speed, km / h. 150

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission country of origin India
FAQ

Datsun redi-GO questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Datsun redi-GO?

This page lists 3 trims for the Datsun redi-GO, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Datsun redi-GO?

The listed configurations show a power range of 54-68 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Datsun redi-GO?

The available specification data shows engine displacement from 799-996 cc across the trims listed on this page.

Which transmissions are listed for the Datsun redi-GO?

The transmission options currently shown for this model are: 5. Open a trim section to see the full data for a specific configuration.

Are there photos for the Datsun redi-GO?

Yes. The gallery includes 22 photos for the Datsun redi-GO, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
