Hyundai specifications

Hyundai Veloster specifications and photos

Hyundai Veloster specifications are shown with trim options, key technical data, and a model photo gallery. Compare 5 configurations by engine size, power, seating, and transmission. The gallery includes 22 photos for visual reference.

Years 2018
Body type hatchback
Trims 5
Photos 22
Hyundai Veloster 2018 hatchback
Overview

Hyundai Veloster at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Hyundai Veloster page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 140-204 hp and 1353-1998 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 140-204 hp
  • Engine displacement: 1353-1998 cc
  • Transmissions: 7, 6, 6-speed manual
  • Seating: 4 seats
Research hub

Photos, trims and specifications for Hyundai Veloster

This model page brings gallery images, trim comparison, and detailed technical data together for the 2018 generation.

Open photo gallery 22 images Compare trims 5 configurations View detailed specs 1353-1998 cc Explore related pages Hyundai and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 140-204 hp
Engine displacement 1353-1998 cc
Seating 4 seats
Transmissions 7, 6, 6-speed manual
Trim / modification Engine Power Seats Transmission
1.4 T-GDi (140 hp) 7-DCT 1353 cc 140 hp 4 7
2.0 MPi (147 hp) 6-MP 1998 cc 147 hp 4 6
2.0 MPi (147 HP) 6-car 1998 cc 147 hp 4 6
1.6 T-GDi (204 HP) 6-speed manual 1591 cc 204 hp 4 6-speed manual
1.6 T-GDi (204 hp) 7-DCT 1591 cc 204 hp 4 7

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

1.4 T-GDi (140 hp) 7-DCT 2.0 MPi (147 hp) 6-MP 2.0 MPi (147 HP) 6-car 1.6 T-GDi (204 HP) 6-speed manual 1.6 T-GDi (204 hp) 7-DCT
1.4 T-GDi (140 hp) 7-DCT 30 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1353
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 140
Torque, Nm 242
RPM at max torque 1500-3200
Engine 1.4 T-GDi
RPM at max power 6000
Turbo +
Engine code G4LD

Dimensions

Seats 4
Length mm 4240
Height mm 1400
Wheelbase mm 2650
Front track, mm 1549
Rear track, mm 1563
Kerb weight, kg 1270
Fuel tank, l 50
Width (without mirrors) mm 1800

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.4
Fuel consumption (urban), l. 100 km 6.8
Fuel consumption (combined), l. 100 km 7.6

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7-speed dual-clutch
Gearbox 2 clutch robot
2.0 MPi (147 hp) 6-MP 26 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 147
Torque, Nm 179
RPM at max torque 4500
Engine 2.0 MPi
RPM at max power 6200

Dimensions

Seats 4
Length mm 4240
Height mm 1400
Wheelbase mm 2650
Front track, mm 1549
Rear track, mm 1563
Kerb weight, kg 1270
Fuel tank, l 50
Width (without mirrors) mm 1800

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
2.0 MPi (147 HP) 6-car 27 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 147
Torque, Nm 179
RPM at max torque 4500
Engine 2.0 MPi
RPM at max power 6200

Dimensions

Seats 4
Length mm 4240
Height mm 1400
Wheelbase mm 2650
Front track, mm 1549
Rear track, mm 1563
Kerb weight, kg 1270
Fuel tank, l 50
Width (without mirrors) mm 1800

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-car
Gearbox Machine
Transmission manufacturer Hyundai-KIA
Transmission country of origin Korea
1.6 T-GDi (204 HP) 6-speed manual 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1591
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 204
Torque, Nm 265
RPM at max torque 1500-4500
Engine 1.6 T-GDi
RPM at max power 6000
Turbo +
Engine code G4FJ

Dimensions

Seats 4
Length mm 4240
Height mm 1400
Wheelbase mm 2650
Front track, mm 1549
Rear track, mm 1563
Kerb weight, kg 1270
Fuel tank, l 50
Width (without mirrors) mm 1800

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.8
Fuel consumption (urban), l. 100 km 7.1
Fuel consumption (combined), l. 100 km 8.1

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.6 T-GDi (204 hp) 7-DCT 30 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1591
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 204
Torque, Nm 265
RPM at max torque 1500-4500
Engine 1.6 T-GDi
RPM at max power 6000
Turbo +
Engine code G4FJ

Dimensions

Seats 4
Length mm 4240
Height mm 1400
Wheelbase mm 2650
Front track, mm 1549
Rear track, mm 1563
Kerb weight, kg 1270
Fuel tank, l 50
Width (without mirrors) mm 1800

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9
Fuel consumption (urban), l. 100 km 7
Fuel consumption (combined), l. 100 km 8.1

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7-speed dual-clutch
Gearbox 2 clutch robot
FAQ

Hyundai Veloster questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Hyundai Veloster?

This page lists 5 trims for the Hyundai Veloster, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Hyundai Veloster?

The listed configurations show a power range of 140-204 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Hyundai Veloster?

The available specification data shows engine displacement from 1353-1998 cc across the trims listed on this page.

Which transmissions are listed for the Hyundai Veloster?

The transmission options currently shown for this model are: 7, 6, 6-speed manual. Open a trim section to see the full data for a specific configuration.

Are there photos for the Hyundai Veloster?

Yes. The gallery includes 22 photos for the Hyundai Veloster, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
