Nissan Sentra specifications and photos

Nissan Sentra specifications are shown with trim options, key technical data, and a model photo gallery. Compare 6 configurations by engine size, power, seating, and transmission. The gallery includes 23 photos for visual reference.

Years 2016 - 2020
Body type sedan
Trims 6
Photos 23
Nissan Sentra 2016 sedan
Overview

Nissan Sentra at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Nissan Sentra page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 132-188 hp and 1618-1798 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 132-188 hp
  • Engine displacement: 1618-1798 cc
  • Transmissions: 6-speed manual
  • Seating: 5 seats
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 132-188 hp
Engine displacement 1618-1798 cc
Seating 5 seats
Transmissions 6-speed manual
Trim / modification Engine Power Seats Transmission
1.8 MT 1798 cc 132 hp 5 -
1.8 AT 1798 cc 132 hp 5 -
1.8 (132 h.p.) 6-speed manual 1798 cc 132 hp 5 6-speed manual
1.8 (132 h.p.) Xtronic CVT 1798 cc 132 hp 5 -
1.6i (188 h.p.) 6-speed manual 1618 cc 188 hp 5 6-speed manual
1.6i (188 HP) Xtronic CVT 1618 cc 188 hp 5 -

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

1.8 MT 1.8 AT 1.8 (132 h.p.) 6-speed manual 1.8 (132 h.p.) Xtronic CVT 1.6i (188 h.p.) 6-speed manual 1.6i (188 HP) Xtronic CVT
1.8 MT 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1798
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 132
Torque, Nm 174
RPM at max torque 3600
Engine 1.8
Compression 9.9
RPM at max power 6000
Engine code MRA8DE

Dimensions

Seats 5
Length mm 4625
Width 1760
Height mm 1496
Wheelbase mm 2700
Front track, mm 1529
Rear track, mm 1529
Kerb weight, kg 1292
Trunk capacity, L 425
Fuel tank, l 50

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Torsion beam with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Drum

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.1
Fuel consumption (urban), l. 100 km 6.2

Transmission and drive

Automatic transmission +
Drive Front
Transmission CVT
Gearbox Variable speed drive
Transmission manufacturer Jatco
Transmission country of origin Japan

Equipment

Wheels

Disc diameter 16
Tires 205/55R16
1.8 AT 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1798
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 132
Torque, Nm 174
RPM at max torque 3600
Engine 1.8
Compression 9.9
RPM at max power 6000
Engine code MRA8DE

Dimensions

Seats 5
Length mm 4625
Width 1760
Height mm 1496
Wheelbase mm 2700
Front track, mm 1529
Rear track, mm 1529
Kerb weight, kg 1296
Trunk capacity, L 425
Fuel tank, l 50

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Torsion beam with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Drum

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.1
Fuel consumption (urban), l. 100 km 6.2

Transmission and drive

Automatic transmission +
Drive Front
Transmission CVT
Gearbox Variable speed drive
Transmission manufacturer Jatco
Transmission country of origin Japan

Equipment

Wheels

Disc diameter 16
Tires 205/55R16
1.8 (132 h.p.) 6-speed manual 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1798
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 132
Torque, Nm 174
RPM at max torque 3600
Engine 1.8
Compression 9.9
RPM at max power 6000
Engine code MRA8DE

Dimensions

Seats 5
Length mm 4625
Width 1760
Height mm 1496
Wheelbase mm 2700
Front track, mm 1529
Rear track, mm 1529
Kerb weight, kg 1296
Trunk capacity, L 425
Fuel tank, l 50

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.7
Fuel consumption (urban), l. 100 km 6.5

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Nissan
Transmission country of origin Japan
1.8 (132 h.p.) Xtronic CVT 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1798
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 132
Torque, Nm 174
RPM at max torque 3600
Engine 1.8
Compression 9.9
RPM at max power 6000
Engine code MRA8DE

Dimensions

Seats 5
Length mm 4625
Width 1760
Height mm 1496
Wheelbase mm 2700
Front track, mm 1529
Rear track, mm 1529
Kerb weight, kg 1296
Trunk capacity, L 425
Fuel tank, l 50

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.1
Fuel consumption (urban), l. 100 km 6.2

Transmission and drive

Automatic transmission +
Drive Front
Transmission CVT
Gearbox Variable speed drive
Transmission manufacturer Jatco
Transmission country of origin Japan
1.6i (188 h.p.) 6-speed manual 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1618
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 188
Torque, Nm 240
RPM at max torque 5200
Engine 1.6i
RPM at max power 5600
Turbo +
Engine code MR16DDT

Dimensions

Seats 5
Length mm 4625
Width 1760
Height mm 1496
Wheelbase mm 2700
Front track, mm 1529
Rear track, mm 1529
Kerb weight, kg 1296
Trunk capacity, L 425
Fuel tank, l 50

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9.1
Fuel consumption (urban), l. 100 km 7.3
Fuel consumption (combined), l. 100 km 8.2

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Nissan
Transmission country of origin Japan
1.6i (188 HP) Xtronic CVT 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1618
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 188
Torque, Nm 240
RPM at max torque 5200
Engine 1.6i
RPM at max power 5600
Turbo +
Engine code MR16DDT

Dimensions

Seats 5
Length mm 4625
Width 1760
Height mm 1496
Wheelbase mm 2700
Front track, mm 1529
Rear track, mm 1529
Kerb weight, kg 1296
Trunk capacity, L 425
Fuel tank, l 50

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9.5
Fuel consumption (urban), l. 100 km 7.6
Fuel consumption (combined), l. 100 km 8.5

Transmission and drive

Automatic transmission +
Drive Front
Transmission CVT
Gearbox Variable speed drive
Transmission manufacturer Jatco
Transmission country of origin Japan
FAQ

Nissan Sentra questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Nissan Sentra?

This page lists 6 trims for the Nissan Sentra, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Nissan Sentra?

The listed configurations show a power range of 132-188 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Nissan Sentra?

The available specification data shows engine displacement from 1618-1798 cc across the trims listed on this page.

Which transmissions are listed for the Nissan Sentra?

The transmission options currently shown for this model are: 6-speed manual. Open a trim section to see the full data for a specific configuration.

Are there photos for the Nissan Sentra?

Yes. The gallery includes 23 photos for the Nissan Sentra, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
