Opel specifications

Opel Insignia Grand Sport specifications and photos

Opel Insignia Grand Sport specifications are shown with trim options, key technical data, and a model photo gallery. Compare 5 configurations by engine size, power, seating, and transmission. The gallery includes 19 photos for visual reference.

Years 2020
Body type liftback
Trims 5
Photos 19
Opel Insignia Grand Sport 2020 liftback
Overview

Opel Insignia Grand Sport at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Opel Insignia Grand Sport page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 122-230 hp and 1496-1998 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 122-230 hp
  • Engine displacement: 1496-1998 cc
  • Transmissions: 9, 6-speed manual, 8-speed automatic
  • Seating: 5 seats
Research hub

Photos, trims and specifications for Opel Insignia Grand Sport

This model page brings gallery images, trim comparison, and detailed technical data together for the 2020 generation.

Open photo gallery 19 images Compare trims 5 configurations View detailed specs 1496-1998 cc Explore related pages Opel and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 122-230 hp
Engine displacement 1496-1998 cc
Seating 5 seats
Transmissions 9, 6-speed manual, 8-speed automatic
Trim / modification Engine Power Seats Transmission
2.0i (200 h.p.) 9-car 1998 cc 200 hp 5 9
2.0i (230 hp) 9-auto 4x4 1998 cc 230 hp 5 9
1.5 BlueHDi (122 h.p.) 6-speed manual 1496 cc 122 hp 5 6-speed manual
2.0 CDTi (174 HP) 6-speed manual 1955 cc 174 hp 5 6-speed manual
2.0 CDTi (174 HP) 8-speed automatic 1955 cc 174 hp 5 8-speed automatic

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

2.0i (200 h.p.) 9-car 2.0i (230 hp) 9-auto 4x4 1.5 BlueHDi (122 h.p.) 6-speed manual 2.0 CDTi (174 HP) 6-speed manual 2.0 CDTi (174 HP) 8-speed automatic
2.0i (200 h.p.) 9-car 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 200
Torque, Nm 350
RPM at max torque 1500-4000
Engine 2.0i
Compression 10,0
RPM at max power 4250-600
Turbo +

Dimensions

Seats 5
Length mm 4897
Width 2093
Height mm 1455
Wheelbase mm 2829
Front track, mm 1607
Rear track, mm 1610
Trunk capacity, L 490
Fuel tank, l 62
Turning circle, m 11.1
Width (without mirrors) mm 1863

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.7
Fuel consumption (urban), l. 100 km 5.1
Fuel consumption (combined), l. 100 km 6.4
Acceleration (0-100 km/h), s 7.7
The maximum speed, km / h. 235
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Front
Transmission 9-car
Gearbox Machine
Transmission manufacturer GM
2.0i (230 hp) 9-auto 4x4 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 230
Torque, Nm 350
RPM at max torque 1500-4000
Engine 2.0i
RPM at max power 5000
Turbo +

Dimensions

Seats 5
Length mm 4897
Width 2093
Height mm 1455
Wheelbase mm 2829
Front track, mm 1607
Rear track, mm 1610
Trunk capacity, L 490
Fuel tank, l 62
Turning circle, m 11.1
Width (without mirrors) mm 1863

Performance and fuel consumption

Fuel consumption (combined), l. 100 km 6.9
Acceleration (0-100 km/h), s 7.4
The maximum speed, km / h. 237
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Full
Transmission 9-car
Gearbox Machine
Transmission manufacturer GM
1.5 BlueHDi (122 h.p.) 6-speed manual 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1496
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 122
Torque, Nm 300
RPM at max torque 1750-2500
Engine 1.5 BlueHDi
Compression 15.5
RPM at max power 3500
Turbo +

Dimensions

Seats 5
Length mm 4897
Width 2093
Height mm 1455
Wheelbase mm 2829
Front track, mm 1607
Rear track, mm 1610
Trunk capacity, L 490
Fuel tank, l 62
Turning circle, m 11.1
Width (without mirrors) mm 1863

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 4.9
Fuel consumption (urban), l. 100 km 3.7
Fuel consumption (combined), l. 100 km 4.2
Acceleration (0-100 km/h), s 10.8
The maximum speed, km / h. 208
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer PSA Group
Transmission country of origin France
2.0 CDTi (174 HP) 6-speed manual 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1955
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 174
Torque, Nm 380
RPM at max torque 1500-2750
Engine 2.0 CDTi
Compression 15,5
RPM at max power 3500
Turbo +

Dimensions

Seats 5
Length mm 4897
Width 2093
Height mm 1455
Wheelbase mm 2829
Front track, mm 1607
Rear track, mm 1610
Trunk capacity, L 490
Fuel tank, l 62
Turning circle, m 11.1
Width (without mirrors) mm 1863

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.6
Fuel consumption (urban), l. 100 km 3.5
Fuel consumption (combined), l. 100 km 4.3
Acceleration (0-100 km/h), s 8
The maximum speed, km / h. 226
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer General Motors
Transmission country of origin +
2.0 CDTi (174 HP) 8-speed automatic 37 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1955
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 174
Torque, Nm 380
RPM at max torque 1500-2750
Engine 2.0 CDTi
Compression 15,5
RPM at max power 3500
Turbo +

Dimensions

Seats 5
Length mm 4897
Width 2093
Height mm 1455
Wheelbase mm 2829
Front track, mm 1607
Rear track, mm 1610
Trunk capacity, L 490
Fuel tank, l 62
Turning circle, m 11.1
Width (without mirrors) mm 1863

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.9
Fuel consumption (urban), l. 100 km 4
Fuel consumption (combined), l. 100 km 4.7
Acceleration (0-100 km/h), s 8
The maximum speed, km / h. 223
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Front
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer Aisin
Transmission country of origin Japan
FAQ

Opel Insignia Grand Sport questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Opel Insignia Grand Sport?

This page lists 5 trims for the Opel Insignia Grand Sport, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Opel Insignia Grand Sport?

The listed configurations show a power range of 122-230 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Opel Insignia Grand Sport?

The available specification data shows engine displacement from 1496-1998 cc across the trims listed on this page.

Which transmissions are listed for the Opel Insignia Grand Sport?

The transmission options currently shown for this model are: 9, 6-speed manual, 8-speed automatic. Open a trim section to see the full data for a specific configuration.

Are there photos for the Opel Insignia Grand Sport?

Yes. The gallery includes 19 photos for the Opel Insignia Grand Sport, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
