Audi A5 Cabriolet specifications and photos

Audi A5 Cabriolet specifications are shown with trim options, key technical data, and a model photo gallery. Compare 19 configurations by engine size, power, seating, and transmission. The gallery includes 14 photos for visual reference.

Years 2017 - 2019
Body type cabriolet
Trims 19
Photos 14
Interior of Audi A5 Cabriolet 2017
Overview

Audi A5 Cabriolet at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Audi A5 Cabriolet page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 150-286 hp and 1968-2967 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 150-286 hp
  • Engine displacement: 1968-2967 cc
  • Transmissions: 6, 7, 6-speed manual
  • Seating: 4 seats
Research hub

Photos, trims and specifications for Audi A5 Cabriolet

This model page brings gallery images, trim comparison, and detailed technical data together for the 2017 generation.

Open photo gallery 14 images Compare trims 19 configurations View detailed specs 1968-2967 cc Explore related pages Audi and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 150-286 hp
Engine displacement 1968-2967 cc
Seating 4 seats
Transmissions 6, 7, 6-speed manual
Trim / modification Engine Power Seats Transmission
2.0 6MT 1984 cc 190 hp 4 6
2.0 AT 1984 cc 190 hp 4 7
2.0 AT (252) 1984 cc 252 hp 4 7
2.0 AT (252) AWD 1984 cc 252 hp 4 7
2.0d AT 1968 cc 190 hp 4 7
2.0d AT AWD 1968 cc 190 hp 4 7
3.0d AT 2967 cc 218 hp 4 7
3.0d AT AWD 2967 cc 218 hp 4 7
40 TFSI 1984 cc 190 hp 4 6
2.0 TFSI (190 HP) 7 S-tronic 1984 cc 190 hp 4 7
2.0 TFSI (252 HP) 7 S-tronic 1984 cc 252 hp 4 7
2.0 TFSI (252 HP) 7 S-tronic 4x4 1984 cc 252 hp 4 7
2.0 TDI (150 h.p.) 6-speed manual 1968 cc 150 hp 4 6-speed manual
35 TDI 1968 cc 150 hp 4 7
40 TDI 1968 cc 190 hp 4 7
40 TDI quattro 1968 cc 190 hp 4 7
3.0 TDI (218 HP) 7 S-tronic 2967 cc 218 hp 4 7
3.0 TDI (218 HP) 7 S-tronic 4x4 2967 cc 218 hp 4 7
3.0 TDI (286 hp) 8-Tiptronic 4x4 2967 cc 286 hp 4 8

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

2.0 6MT 2.0 AT 2.0 AT (252) 2.0 AT (252) AWD 2.0d AT 2.0d AT AWD 3.0d AT 3.0d AT AWD 40 TFSI 2.0 TFSI (190 HP) 7 S-tronic 2.0 TFSI (252 HP) 7 S-tronic 2.0 TFSI (252 HP) 7 S-tronic 4x4 2.0 TDI (150 h.p.) 6-speed manual 35 TDI 40 TDI 40 TDI quattro 3.0 TDI (218 HP) 7 S-tronic 3.0 TDI (218 HP) 7 S-tronic 4x4 3.0 TDI (286 hp) 8-Tiptronic 4x4
2.0 6MT 41 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 320
RPM at max torque 1500-4180
Engine 2.0 TFSI
RPM at max power 4200-6000
Turbo +
Engine code CZPB/CVKB (EA888)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1675
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2110
Width (without mirrors) mm 1846

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.7
Fuel consumption (urban), l. 100 km 5.2
Fuel consumption (combined), l. 100 km 6.1
Acceleration (0-100 km/h), s 7.9
The maximum speed, km / h. 239
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
2.0 AT 43 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 320
RPM at max torque 1500-4180
Engine 2.0 TFSI
RPM at max power 4200-6000
Turbo +
Engine code CZPB/CVKB (EA888)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1705
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2140
Width (without mirrors) mm 1846

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7
Fuel consumption (urban), l. 100 km 5
Fuel consumption (combined), l. 100 km 5.8
Acceleration (0-100 km/h), s 7.9
The maximum speed, km / h. 237
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
2.0 AT (252) 43 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 252
Torque, Nm 370
RPM at max torque 1600-4500
Engine 2.0 TFSI
RPM at max power 5000-6000
Turbo +
Engine code CYRB/DAXB (EA888)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1725
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2150
Width (without mirrors) mm 1846

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Ventilated disc

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8
Fuel consumption (urban), l. 100 km 5.5
Fuel consumption (combined), l. 100 km 6.4
Acceleration (0-100 km/h), s 6.7
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
2.0 AT (252) AWD 43 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 252
Torque, Nm 370
RPM at max torque 1600-4500
Engine 2.0 TFSI
RPM at max power 5000-6000
Turbo +
Engine code CYRB/DAXB (EA888)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1785
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2210
Width (without mirrors) mm 1846

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Ventilated disc

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.2
Fuel consumption (urban), l. 100 km 5.7
Fuel consumption (combined), l. 100 km 6.6
Acceleration (0-100 km/h), s 6.3
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
2.0d AT 44 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 400
RPM at max torque 1900-3300
Engine 2.0 TDI
Compression 15.8
RPM at max power 3500-4000
Turbo +
Engine code DETA/DFHA (EA288)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.3
Fuel consumption (urban), l. 100 km 4.4
Fuel consumption (combined), l. 100 km 4.7
Acceleration (0-100 km/h), s 8.3
The maximum speed, km / h. 232
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
2.0d AT AWD 44 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 400
RPM at max torque 1900-3300
Engine 2.0 TDI
Compression 15.8
RPM at max power 3500-4000
Turbo +
Engine code DETA/DFHA (EA288)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1840
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2280
Width (without mirrors) mm 1846

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.5
Fuel consumption (urban), l. 100 km 4.6
Fuel consumption (combined), l. 100 km 4.9
Acceleration (0-100 km/h), s 7.8
The maximum speed, km / h. 233
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
3.0d AT 43 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2967
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 218
Torque, Nm 400
RPM at max torque 1250-3750
Engine 3.0 TDI
RPM at max power 4000-4750
Turbo +
Engine code CSWB (EA897)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1825
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2250
Width (without mirrors) mm 1846

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.2
Fuel consumption (urban), l. 100 km 4.5
Fuel consumption (combined), l. 100 km 4.8
Acceleration (0-100 km/h), s 7
The maximum speed, km / h. 246
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
3.0d AT AWD 43 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2967
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 218
Torque, Nm 400
RPM at max torque 1250-3750
Engine 3.0 TDI
RPM at max power 4000-4750
Turbo +
Engine code CSWB (EA897)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1895
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2320
Width (without mirrors) mm 1846

Suspension

Type of front suspension Independent with anti-roll bar
Rear suspension Independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.6
Fuel consumption (urban), l. 100 km 5
Fuel consumption (combined), l. 100 km 5.2
Acceleration (0-100 km/h), s 6.8
The maximum speed, km / h. 241
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
40 TFSI 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 320
RPM at max torque 1500-4180
Engine 2.0 TFSI
RPM at max power 4200-6000
Turbo +
Engine code CZPB/CVKB (EA888)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.7
Fuel consumption (urban), l. 100 km 5.2
Fuel consumption (combined), l. 100 km 6.1
Acceleration (0-100 km/h), s 7.9
The maximum speed, km / h. 239
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
2.0 TFSI (190 HP) 7 S-tronic 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 320
RPM at max torque 1500-4180
Engine 2.0 TFSI
RPM at max power 4200-6000
Turbo +
Engine code CZPB/CVKB (EA888)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7
Fuel consumption (urban), l. 100 km 5
Fuel consumption (combined), l. 100 km 5.8
Acceleration (0-100 km/h), s 7.9
The maximum speed, km / h. 237
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
2.0 TFSI (252 HP) 7 S-tronic 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 252
Torque, Nm 370
RPM at max torque 1600-4500
Engine 2.0 TFSI
RPM at max power 5000-6000
Turbo +
Engine code CYRB/DAXB (EA888)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8
Fuel consumption (urban), l. 100 km 5.5
Fuel consumption (combined), l. 100 km 6.4
Acceleration (0-100 km/h), s 6.7
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
2.0 TFSI (252 HP) 7 S-tronic 4x4 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 252
Torque, Nm 370
RPM at max torque 1600-4500
Engine 2.0 TFSI
RPM at max power 5000-6000
Turbo +
Engine code CYRB/DAXB (EA888)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.2
Fuel consumption (urban), l. 100 km 5.7
Fuel consumption (combined), l. 100 km 6.6
Acceleration (0-100 km/h), s 6.3
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
2.0 TDI (150 h.p.) 6-speed manual 37 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 150
Torque, Nm 320
RPM at max torque 1750-3000
Engine 2.0 TDI
Compression 16.2
RPM at max power 3500-4000
Turbo +
Engine code CRBC/CRLB/DEUA

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.1
Fuel consumption (urban), l. 100 km 4.1
Fuel consumption (combined), l. 100 km 4.5
Acceleration (0-100 km/h), s 9.7
The maximum speed, km / h. 215
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
35 TDI 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 150
Torque, Nm 320
RPM at max torque 1750-3000
Engine 2.0 TDI
Compression 16.2
RPM at max power 3500-4000
Turbo +
Engine code CRBC/CRLB/DEUA

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.3
Fuel consumption (urban), l. 100 km 4.3
Fuel consumption (combined), l. 100 km 4.6
Acceleration (0-100 km/h), s 9.6
The maximum speed, km / h. 213
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
40 TDI 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 400
RPM at max torque 1900-3300
Engine 2.0 TDI
Compression 15.8
RPM at max power 3500-4000
Turbo +
Engine code DETA/DFHA (EA288)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.3
Fuel consumption (urban), l. 100 km 4.4
Fuel consumption (combined), l. 100 km 4.7
Acceleration (0-100 km/h), s 8.3
The maximum speed, km / h. 232
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
40 TDI quattro 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1968
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 190
Torque, Nm 400
RPM at max torque 1900-3300
Engine 2.0 TDI
Compression 15.8
RPM at max power 3500-4000
Turbo +
Engine code DETA/DFHA (EA288)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.5
Fuel consumption (urban), l. 100 km 4.6
Fuel consumption (combined), l. 100 km 4.9
Acceleration (0-100 km/h), s 7.8
The maximum speed, km / h. 233
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
3.0 TDI (218 HP) 7 S-tronic 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2967
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 218
Torque, Nm 400
RPM at max torque 1250-3750
Engine 3.0 TDI
RPM at max power 4000-4750
Turbo +
Engine code CSWB (EA897)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.2
Fuel consumption (urban), l. 100 km 4.5
Fuel consumption (combined), l. 100 km 4.8
Acceleration (0-100 km/h), s 7
The maximum speed, km / h. 246
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
3.0 TDI (218 HP) 7 S-tronic 4x4 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2967
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 218
Torque, Nm 400
RPM at max torque 1250-3750
Engine 3.0 TDI
RPM at max power 4000-4750
Turbo +
Engine code CSWB (EA897)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.6
Fuel consumption (urban), l. 100 km 5
Fuel consumption (combined), l. 100 km 5.2
Acceleration (0-100 km/h), s 6.8
The maximum speed, km / h. 241
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
3.0 TDI (286 hp) 8-Tiptronic 4x4 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2967
Cylinders location V-shaped
Number of cylinders 6
Valves 32
Power, hp 286
Torque, Nm 620
RPM at max torque 1500-3000
Engine 3.0 TDI
RPM at max power 3750-4000
Turbo +
Engine code DCPC (EA897)

Dimensions

Seats 4
Length mm 4673
Width 2029
Height mm 1383
Wheelbase mm 2765
Front track, mm 1587
Rear track, mm 1568
Kerb weight, kg 1765
Trunk capacity, L 380
Fuel tank, l 40
Turning circle, m 11.5
Gross weight, kg 2215
Width (without mirrors) mm 1846

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 6.8
Fuel consumption (urban), l. 100 km 5.4
Fuel consumption (combined), l. 100 km 5.9
Acceleration (0-100 km/h), s 5.7
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-Tiptronic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
FAQ

Audi A5 Cabriolet questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Audi A5 Cabriolet?

This page lists 19 trims for the Audi A5 Cabriolet, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Audi A5 Cabriolet?

The listed configurations show a power range of 150-286 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Audi A5 Cabriolet?

The available specification data shows engine displacement from 1968-2967 cc across the trims listed on this page.

Which transmissions are listed for the Audi A5 Cabriolet?

The transmission options currently shown for this model are: 6, 7, 6-speed manual. Open a trim section to see the full data for a specific configuration.

Are there photos for the Audi A5 Cabriolet?

Yes. The gallery includes 14 photos for the Audi A5 Cabriolet, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
