Audi S3 specifications and photos

Audi S3 specifications are shown with trim options, key technical data, and a model photo gallery. Compare 3 configurations by engine size, power, seating, and transmission. The gallery includes 21 photos for visual reference.

Years 2016 - 2018
Body type hatchback
Trims 3
Photos 21
Interior of Audi S3 2016
Overview

Audi S3 at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Audi S3 page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 310 hp and 1984 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 310 hp
  • Engine displacement: 1984 cc
  • Transmissions: 6, 7
  • Seating: 5 seats
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 310 hp
Engine displacement 1984 cc
Seating 5 seats
Transmissions 6, 7
Trim / modification Engine Power Seats Transmission
2.0i 6MT 1984 cc 310 hp 5 6
2.0 TFSI (310 hp) 6-speed 4x4 1984 cc 310 hp 5 6
2.0 TFSI (310 HP) 7 S-tronic 4x4 1984 cc 310 hp 5 7

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

2.0i 6MT 2.0 TFSI (310 hp) 6-speed 4x4 2.0 TFSI (310 HP) 7 S-tronic 4x4
2.0i 6MT 45 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 310
Torque, Nm 380
RPM at max torque 1800-5700
Engine 2.0 TFSI
Compression 9.3
RPM at max power 5500-6200
Turbo +
Engine code CJXG/DJHA (EA888)

Dimensions

Seats 5
Length mm 4252
Width 1966
Height mm 1401
Wheelbase mm 2596
Front track, mm 1535
Rear track, mm 1510
Kerb weight, kg 1480
Trunk capacity, L 325
Fuel tank, l 55
Turning circle, m 10.7
Gross weight, kg 1965
Width (without mirrors) mm 1777

Suspension

Type of front suspension Independent McPherson type with anti-roll bar
Rear suspension Multi-link independent with anti-roll bar

Brake system

The front brakes Ventilated disc
Rear brakes Ventilated disc

Steering

Power steering Electromechanical

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9.1
Fuel consumption (urban), l. 100 km 5.8
Fuel consumption (combined), l. 100 km 7
Acceleration (0-100 km/h), s 5.2
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Full
Transmission 6-speed manual
Gearbox Mechanics

Equipment

Wheels

Disc diameter 18
Rim type Alloy
Tires 225/40R18
2.0 TFSI (310 hp) 6-speed 4x4 37 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 310
Torque, Nm 380
RPM at max torque 1800-5700
Engine 2.0 TFSI
Compression 9.3
RPM at max power 5500-6200
Turbo +
Engine code CJXG/DJHA (EA888)

Dimensions

Seats 5
Length mm 4252
Width 1966
Height mm 1401
Wheelbase mm 2596
Front track, mm 1535
Rear track, mm 1510
Kerb weight, kg 1480
Trunk capacity, L 325
Fuel tank, l 55
Turning circle, m 10.7
Gross weight, kg 1965
Width (without mirrors) mm 1777

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9.1
Fuel consumption (urban), l. 100 km 5.8
Fuel consumption (combined), l. 100 km 7
Acceleration (0-100 km/h), s 5.2
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Full
Transmission 6-speed manual
Gearbox Mechanics
2.0 TFSI (310 HP) 7 S-tronic 4x4 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1984
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 310
Torque, Nm 400
RPM at max torque 2000-5400
Engine 2.0 TFSI
Compression 9.3
RPM at max power 5500-6500
Turbo +
Engine code CJXG/DJHA (EA888)

Dimensions

Seats 5
Length mm 4252
Width 1966
Height mm 1401
Wheelbase mm 2596
Front track, mm 1535
Rear track, mm 1510
Kerb weight, kg 1480
Trunk capacity, L 325
Fuel tank, l 55
Turning circle, m 10.7
Gross weight, kg 1965
Width (without mirrors) mm 1777

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.3
Fuel consumption (urban), l. 100 km 5.6
Fuel consumption (combined), l. 100 km 6.6
Acceleration (0-100 km/h), s 4.6
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7 S-tronic
Gearbox 2 clutch robot
Transmission manufacturer BorgWarner
FAQ

Audi S3 questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Audi S3?

This page lists 3 trims for the Audi S3, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Audi S3?

The listed configurations show a power range of 310 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Audi S3?

The available specification data shows engine displacement from 1984 cc across the trims listed on this page.

Which transmissions are listed for the Audi S3?

The transmission options currently shown for this model are: 6, 7. Open a trim section to see the full data for a specific configuration.

Are there photos for the Audi S3?

Yes. The gallery includes 21 photos for the Audi S3, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
