FAW Junpai D60 specifications and photos

FAW Junpai D60 specifications are shown with trim options, key technical data, and a model photo gallery. Compare 4 configurations by engine size, power, seating, and transmission. The gallery includes 16 photos for visual reference.

Years 2014 - 2016
Body type suv
Trims 4
Photos 16
FAW Junpai D60 2014 SUV
Overview

FAW Junpai D60 at a glance

Quick model context before comparing photos and trim-level specifications.

Use this FAW Junpai D60 page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 102-137 hp and 1500-1800 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 102-137 hp
  • Engine displacement: 1500-1800 cc
  • Transmissions: 5, 6, 5-speed manual
  • Seating: 5 seats
Research hub

Photos, trims and specifications for FAW Junpai D60

This model page brings gallery images, trim comparison, and detailed technical data together for the 2014 generation.

Open photo gallery 16 images Compare trims 4 configurations View detailed specs 1500-1800 cc Explore related pages FAW and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 102-137 hp
Engine displacement 1500-1800 cc
Seating 5 seats
Transmissions 5, 6, 5-speed manual
Trim / modification Engine Power Seats Transmission
1.5 MT 1500 cc 102 hp 5 5
1.8 MT 1800 cc 137 hp 5 6
1.5i (102 h.p.) 5-speed manual 1500 cc 102 hp 5 5-speed manual
1.8i (137 h.p.) 6-speed manual 1800 cc 137 hp 5 6-speed manual

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

1.5 MT 1.8 MT 1.5i (102 h.p.) 5-speed manual 1.8i (137 h.p.) 6-speed manual
1.5 MT 37 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 102
Torque, Nm 135
RPM at max torque 4400
Engine 1.5i
Compression 10.5
RPM at max power 6000
Engine code CA4GA5

Dimensions

Seats 5
Length mm 4170
Width 1765
Height mm 1625
Wheelbase mm 2557
Front track, mm 1485
Rear track, mm 1475
Kerb weight, kg 1206
Fuel tank, l 48
Turning circle, m 10.9
Ground clearance, mm 181

Suspension

Type of front suspension Independent Type McPherson
Rear suspension Torsion beam

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (combined), l. 100 km 6.6
The maximum speed, km / h. 168

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission manufacturer Aisin
Transmission country of origin Japan

Equipment

Wheels

Disc diameter 16
Tires 205/60R16
1.8 MT 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1800
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 137
Torque, Nm 172
RPM at max torque 4000
Engine 1.8i
RPM at max power 6000

Dimensions

Seats 5
Length mm 4170
Width 1765
Height mm 1625
Wheelbase mm 2557
Front track, mm 1485
Rear track, mm 1475
Kerb weight, kg 1276
Fuel tank, l 48
Turning circle, m 10.9
Ground clearance, mm 181

Suspension

Type of front suspension Independent Type McPherson
Rear suspension Torsion beam

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (combined), l. 100 km 7.2
The maximum speed, km / h. 175
The rate of toxicity Euro V

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Aisin
Transmission country of origin Japan

Equipment

Wheels

Disc diameter 16
Tires 205/60R16
1.5i (102 h.p.) 5-speed manual 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 102
Torque, Nm 135
RPM at max torque 4400
Engine 1.5i
Compression 10.5
RPM at max power 6000
Engine code CA4GA5

Dimensions

Seats 5
Length mm 4170
Width 1765
Height mm 1625
Wheelbase mm 2557
Front track, mm 1485
Rear track, mm 1475
Kerb weight, kg 1276
Fuel tank, l 48
Turning circle, m 10.9
Ground clearance, mm 181

Performance and fuel consumption

Fuel consumption (combined), l. 100 km 6.6
The maximum speed, km / h. 168

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission manufacturer Aisin
Transmission country of origin Japan
1.8i (137 h.p.) 6-speed manual 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1800
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 137
Torque, Nm 172
RPM at max torque 4000
Engine 1.8i
RPM at max power 6000

Dimensions

Seats 5
Length mm 4170
Width 1765
Height mm 1625
Wheelbase mm 2557
Front track, mm 1485
Rear track, mm 1475
Kerb weight, kg 1276
Fuel tank, l 48
Turning circle, m 10.9
Ground clearance, mm 181

Performance and fuel consumption

Fuel consumption (combined), l. 100 km 7.2
The maximum speed, km / h. 175
The rate of toxicity Euro V

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Aisin
Transmission country of origin Japan
FAQ

FAW Junpai D60 questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the FAW Junpai D60?

This page lists 4 trims for the FAW Junpai D60, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the FAW Junpai D60?

The listed configurations show a power range of 102-137 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the FAW Junpai D60?

The available specification data shows engine displacement from 1500-1800 cc across the trims listed on this page.

Which transmissions are listed for the FAW Junpai D60?

The transmission options currently shown for this model are: 5, 6, 5-speed manual. Open a trim section to see the full data for a specific configuration.

Are there photos for the FAW Junpai D60?

Yes. The gallery includes 16 photos for the FAW Junpai D60, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
