GMC Acadia specifications and photos

GMC Acadia specifications are shown with trim options, key technical data, and a model photo gallery. Compare 8 configurations by engine size, power, seating, and transmission. The gallery includes 24 photos for visual reference.

Years 2016 - 2019
Body type suv
Trims 8
Photos 24
GMC Acadia 2016 SUV
Overview

GMC Acadia at a glance

Quick model context before comparing photos and trim-level specifications.

Use this GMC Acadia page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 194-314 hp and 2500-3564 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 194-314 hp
  • Engine displacement: 2500-3564 cc
  • Transmissions: 6, 6-speed automatic
  • Seating: 7 seats
Research hub

Photos, trims and specifications for GMC Acadia

This model page brings gallery images, trim comparison, and detailed technical data together for the 2016 generation.

Open photo gallery 24 images Compare trims 8 configurations View detailed specs 2500-3564 cc Explore related pages GMC and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 194-314 hp
Engine displacement 2500-3564 cc
Seating 7 seats
Transmissions 6, 6-speed automatic
Trim / modification Engine Power Seats Transmission
2.5 AT 2500 cc 194 hp 7 6
2.5 AT AWD 2500 cc 194 hp 7 6
3.6 AT 3564 cc 314 hp 7 6
3.6 AT AWD 3564 cc 314 hp 7 6
2.5i (194 HP) 6-speed automatic 2500 cc 194 hp 7 6-speed automatic
2.5i (194 h.p.) 6-speed automatic transmission 4x4 2500 cc 194 hp 7 6-speed automatic
3.6i (314 HP) 6-speed automatic 3564 cc 314 hp 7 6-speed automatic
3.6i (314 hp) 6-speed 4x4 automatic transmission 3564 cc 314 hp 7 6

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

2.5 AT 2.5 AT AWD 3.6 AT 3.6 AT AWD 2.5i (194 HP) 6-speed automatic 2.5i (194 h.p.) 6-speed automatic transmission 4x4 3.6i (314 HP) 6-speed automatic 3.6i (314 hp) 6-speed 4x4 automatic transmission
2.5 AT 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 194
Torque, Nm 258
RPM at max torque 4400
Engine 2.5i
RPM at max power 6300
Engine code LCV

Dimensions

Seats 7
Length mm 4917
Height mm 1676
Wheelbase mm 2857
Front track, mm 1638
Rear track, mm 1638
Kerb weight, kg 1794
Trunk capacity, L 363
Fuel tank, l 72
Turning circle, m 11.8
Ground clearance, mm 183
Width (without mirrors) mm 1915

Suspension

Type of front suspension Independent
Rear suspension Independent

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 11.2
Fuel consumption (urban), l. 100 km 9

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
2.5 AT AWD 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 194
Torque, Nm 258
RPM at max torque 4400
Engine 2.5i
RPM at max power 6300
Engine code LCV

Dimensions

Seats 7
Length mm 4917
Height mm 1676
Wheelbase mm 2857
Front track, mm 1638
Rear track, mm 1638
Kerb weight, kg 1794
Trunk capacity, L 363
Fuel tank, l 83
Turning circle, m 11.8
Ground clearance, mm 183
Width (without mirrors) mm 1915

Suspension

Type of front suspension Independent
Rear suspension Independent

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13
Fuel consumption (urban), l. 100 km 9.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6 AT 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3564
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 314
Torque, Nm 368
RPM at max torque 5000
Engine 3.6i
Compression 11.5
RPM at max power 6700
Engine code LGX

Dimensions

Seats 7
Length mm 4917
Height mm 1676
Wheelbase mm 2857
Front track, mm 1638
Rear track, mm 1638
Kerb weight, kg 1794
Trunk capacity, L 363
Fuel tank, l 72
Turning circle, m 11.8
Ground clearance, mm 183
Width (without mirrors) mm 1915

Suspension

Type of front suspension Independent
Rear suspension Independent

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13
Fuel consumption (urban), l. 100 km 9.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6 AT AWD 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3564
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 314
Torque, Nm 368
RPM at max torque 5000
Engine 3.6i
Compression 11.5
RPM at max power 6700
Engine code LGX

Dimensions

Seats 7
Length mm 4917
Height mm 1676
Wheelbase mm 2857
Front track, mm 1638
Rear track, mm 1638
Kerb weight, kg 1794
Trunk capacity, L 363
Fuel tank, l 83
Turning circle, m 11.8
Ground clearance, mm 183
Width (without mirrors) mm 1915

Suspension

Type of front suspension Independent
Rear suspension Independent

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13
Fuel consumption (urban), l. 100 km 9.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
2.5i (194 HP) 6-speed automatic 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 194
Torque, Nm 258
RPM at max torque 4400
Engine 2.5i
RPM at max power 6300
Engine code LCV

Dimensions

Seats 7
Length mm 4917
Height mm 1676
Wheelbase mm 2857
Front track, mm 1638
Rear track, mm 1638
Trunk capacity, L 363
Fuel tank, l 82
Turning circle, m 11.8
Ground clearance, mm 183
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 11.2
Fuel consumption (urban), l. 100 km 9

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
2.5i (194 h.p.) 6-speed automatic transmission 4x4 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 194
Torque, Nm 258
RPM at max torque 4400
Engine 2.5i
RPM at max power 6300
Engine code LCV

Dimensions

Seats 7
Length mm 4917
Height mm 1676
Wheelbase mm 2857
Front track, mm 1638
Rear track, mm 1638
Trunk capacity, L 363
Fuel tank, l 82
Turning circle, m 11.8
Ground clearance, mm 183
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13
Fuel consumption (urban), l. 100 km 9.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6i (314 HP) 6-speed automatic 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3564
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 314
Torque, Nm 368
RPM at max torque 5000
Engine 3.6i
Compression 11.5
RPM at max power 6700
Engine code LGX

Dimensions

Seats 7
Length mm 4917
Height mm 1676
Wheelbase mm 2857
Front track, mm 1638
Rear track, mm 1638
Trunk capacity, L 363
Fuel tank, l 82
Turning circle, m 11.8
Ground clearance, mm 183
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13
Fuel consumption (urban), l. 100 km 9.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
3.6i (314 hp) 6-speed 4x4 automatic transmission 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3564
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 314
Torque, Nm 368
RPM at max torque 5000
Engine 3.6i
Compression 11.5
RPM at max power 6700
Engine code LGX

Dimensions

Seats 7
Length mm 4917
Height mm 1676
Wheelbase mm 2857
Front track, mm 1638
Rear track, mm 1638
Trunk capacity, L 363
Fuel tank, l 82
Turning circle, m 11.8
Ground clearance, mm 183
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13
Fuel consumption (urban), l. 100 km 9.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
FAQ

GMC Acadia questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the GMC Acadia?

This page lists 8 trims for the GMC Acadia, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the GMC Acadia?

The listed configurations show a power range of 194-314 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the GMC Acadia?

The available specification data shows engine displacement from 2500-3564 cc across the trims listed on this page.

Which transmissions are listed for the GMC Acadia?

The transmission options currently shown for this model are: 6, 6-speed automatic. Open a trim section to see the full data for a specific configuration.

Are there photos for the GMC Acadia?

Yes. The gallery includes 24 photos for the GMC Acadia, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
