Hyundai specifications

Hyundai i30 Wagon specifications and photos

Hyundai i30 Wagon specifications are shown with trim options, key technical data, and a model photo gallery. Compare 8 configurations by engine size, power, seating, and transmission. The gallery includes 17 photos for visual reference.

Years 2018
Body type wagon
Trims 8
Photos 17
Hyundai i30 Wagon 2018 photo
Overview

Hyundai i30 Wagon at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Hyundai i30 Wagon page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 100-140 hp and 998-1582 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 100-140 hp
  • Engine displacement: 998-1582 cc
  • Transmissions: 6, 6-speed manual, 7
  • Seating: 5 seats
Research hub

Photos, trims and specifications for Hyundai i30 Wagon

This model page brings gallery images, trim comparison, and detailed technical data together for the 2018 generation.

Open photo gallery 17 images Compare trims 8 configurations View detailed specs 998-1582 cc Explore related pages Hyundai and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 100-140 hp
Engine displacement 998-1582 cc
Seating 5 seats
Transmissions 6, 6-speed manual, 7
Trim / modification Engine Power Seats Transmission
1.4 MPi (100 hp) 6-MPP 1368 cc 100 hp 5 6
1.0 T-GDI (120 h.p.) 6-speed manual 998 cc 120 hp 5 6-speed manual
1.4 T-GDi (140 h.p.) 6-speed manual 1353 cc 140 hp 5 6-speed manual
1.4 T-GDi (140 hp) 7-DCT 1353 cc 140 hp 5 7
1.6 CRDI (115 hp) 6-speed manual 1582 cc 115 hp 5 6-speed manual
1.6 CRDI (115 hp) 7-DCT 1582 cc 115 hp 5 7
1.6 CRDI (136 hp) 6-speed manual 1582 cc 136 hp 5 6-speed manual
1.6 CRDI (136 hp) 7-DCT 1582 cc 136 hp 5 7

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

1.4 MPi (100 hp) 6-MPP 1.0 T-GDI (120 h.p.) 6-speed manual 1.4 T-GDi (140 h.p.) 6-speed manual 1.4 T-GDi (140 hp) 7-DCT 1.6 CRDI (115 hp) 6-speed manual 1.6 CRDI (115 hp) 7-DCT 1.6 CRDI (136 hp) 6-speed manual 1.6 CRDI (136 hp) 7-DCT
1.4 MPi (100 hp) 6-MPP 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1368
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 100
Torque, Nm 134
RPM at max torque 3500
Engine 1.4 MPi
Compression 10.5
RPM at max power 6000
Engine code G4LC

Dimensions

Seats 5
Length mm 4585
Height mm 1465
Wheelbase mm 2650
Front track, mm 1559
Rear track, mm 1567
Trunk capacity, L 602
Fuel tank, l 50
Width (without mirrors) mm 1795

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.9
Fuel consumption (urban), l. 100 km 5.2
Fuel consumption (combined), l. 100 km 6.2
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.0 T-GDI (120 h.p.) 6-speed manual 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 998
Cylinders location In-line
Number of cylinders 3
Valves 12
Power, hp 120
Torque, Nm 172
RPM at max torque 1500-4000
Engine 1.0 T-GDI
Compression 10.0
RPM at max power 6000
Turbo +
Engine code G3LC

Dimensions

Seats 5
Length mm 4585
Height mm 1465
Wheelbase mm 2650
Front track, mm 1559
Rear track, mm 1567
Trunk capacity, L 602
Fuel tank, l 50
Width (without mirrors) mm 1795

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 6.5
Fuel consumption (urban), l. 100 km 4.9
Fuel consumption (combined), l. 100 km 5.5
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.4 T-GDi (140 h.p.) 6-speed manual 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1353
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 140
Torque, Nm 242
RPM at max torque 1500-3200
Engine 1.4 T-GDi
RPM at max power 6000
Turbo +
Engine code G4LD

Dimensions

Seats 5
Length mm 4585
Height mm 1465
Wheelbase mm 2650
Front track, mm 1559
Rear track, mm 1567
Trunk capacity, L 602
Fuel tank, l 50
Width (without mirrors) mm 1795

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.2
Fuel consumption (urban), l. 100 km 5.1
Fuel consumption (combined), l. 100 km 5.9
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.4 T-GDi (140 hp) 7-DCT 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1353
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 140
Torque, Nm 242
RPM at max torque 1500-3200
Engine 1.4 T-GDi
RPM at max power 6000
Turbo +
Engine code G4LD

Dimensions

Seats 5
Length mm 4585
Height mm 1465
Wheelbase mm 2650
Front track, mm 1559
Rear track, mm 1567
Trunk capacity, L 602
Fuel tank, l 50
Width (without mirrors) mm 1795

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 6.7
Fuel consumption (urban), l. 100 km 5.1
Fuel consumption (combined), l. 100 km 5.7
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7-speed dual-clutch
Gearbox 2 clutch robot
1.6 CRDI (115 hp) 6-speed manual 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1582
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 115
Torque, Nm 260
RPM at max torque 1500-2750
Engine 1.6 CRDI
Compression 17.3
RPM at max power 4000
Engine code D4FB

Dimensions

Seats 5
Length mm 4585
Height mm 1465
Wheelbase mm 2650
Front track, mm 1559
Rear track, mm 1567
Trunk capacity, L 602
Fuel tank, l 50
Width (without mirrors) mm 1795

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 4.7
Fuel consumption (urban), l. 100 km 4
Fuel consumption (combined), l. 100 km 4.3
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.6 CRDI (115 hp) 7-DCT 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1582
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 115
Torque, Nm 260
RPM at max torque 1500-2750
Engine 1.6 CRDI
Compression 17.3
RPM at max power 4000
Engine code D4FB

Dimensions

Seats 5
Length mm 4585
Height mm 1465
Wheelbase mm 2650
Front track, mm 1559
Rear track, mm 1567
Trunk capacity, L 602
Fuel tank, l 50
Width (without mirrors) mm 1795

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 4.4
Fuel consumption (urban), l. 100 km 3.9
Fuel consumption (combined), l. 100 km 4.1
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7-speed dual-clutch
Gearbox 2 clutch robot
1.6 CRDI (136 hp) 6-speed manual 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1582
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 136
Torque, Nm 280
RPM at max torque 1500-3000
Engine 1.6 CRDI
Compression 17.3
RPM at max power 4000
Turbo +
Engine code D4FB

Dimensions

Seats 5
Length mm 4585
Height mm 1465
Wheelbase mm 2650
Front track, mm 1559
Rear track, mm 1567
Trunk capacity, L 602
Fuel tank, l 50
Width (without mirrors) mm 1795

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 4.9
Fuel consumption (urban), l. 100 km 4.2
Fuel consumption (combined), l. 100 km 4.4
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.6 CRDI (136 hp) 7-DCT 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1582
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 136
Torque, Nm 300
RPM at max torque 1750-2500
Engine 1.6 CRDI
Compression 17.3
RPM at max power 4000
Turbo +

Dimensions

Seats 5
Length mm 4585
Height mm 1465
Wheelbase mm 2650
Front track, mm 1559
Rear track, mm 1567
Trunk capacity, L 602
Fuel tank, l 50
Width (without mirrors) mm 1795

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 4.6
Fuel consumption (urban), l. 100 km 4.1
Fuel consumption (combined), l. 100 km 4.3
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7-speed dual-clutch
Gearbox 2 clutch robot
FAQ

Hyundai i30 Wagon questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Hyundai i30 Wagon?

This page lists 8 trims for the Hyundai i30 Wagon, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Hyundai i30 Wagon?

The listed configurations show a power range of 100-140 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Hyundai i30 Wagon?

The available specification data shows engine displacement from 998-1582 cc across the trims listed on this page.

Which transmissions are listed for the Hyundai i30 Wagon?

The transmission options currently shown for this model are: 6, 6-speed manual, 7. Open a trim section to see the full data for a specific configuration.

Are there photos for the Hyundai i30 Wagon?

Yes. The gallery includes 17 photos for the Hyundai i30 Wagon, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
