Jaguar F-Type specifications and photos

Jaguar F-Type specifications are shown with trim options, key technical data, and a model photo gallery. Compare 21 configurations by engine size, power, seating, and transmission. The gallery includes 26 photos for visual reference.

Years 2017 - 2019
Body type cabriolet
Trims 21
Photos 26
Jaguar F-Type 2017 cabriolet
Overview

Jaguar F-Type at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Jaguar F-Type page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 300-575 hp and 1997-4999 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 300-575 hp
  • Engine displacement: 1997-4999 cc
  • Transmissions: 8, 6
  • Seating: 2 seats
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 300-575 hp
Engine displacement 1997-4999 cc
Seating 2 seats
Transmissions 8, 6
Trim / modification Engine Power Seats Transmission
2.0 8AT F-TYPE (300) 1997 cc 300 hp 2 8
2.0 8AT F-TYPE R-DYNAMIC (300) 1997 cc 300 hp 2 8
3.0 6MT F-TYPE (340) 2995 cc 340 hp 2 6
3.0 8AT F-TYPE (340) 2995 cc 340 hp 2 8
3.0 6MT F-TYPE (380) 2995 cc 380 hp 2 6
3.0 8AT F-TYPE (380) 2995 cc 380 hp 2 8
3.0 8AT F-TYPE AWD (380) 2995 cc 380 hp 2 8
3.0 8AT F-TYPE (400) 2995 cc 400 hp 2 8
3.0 8AT F-TYPE AWD (400) 2995 cc 400 hp 2 8
5.0 8AT F-TYPE R AWD (550) 4999 cc 550 hp 2 8
5.0 8AT F-TYPE SVR AWD (575) 4999 cc 575 hp 2 8
P300 1997 cc 300 hp 2 8
P340 2995 cc 340 hp 2 6
P340 2995 cc 340 hp 2 8
P380 2995 cc 380 hp 2 6
P380 2995 cc 380 hp 2 8
P380 2995 cc 380 hp 2 8
P400 2995 cc 400 hp 2 8
P400 2995 cc 400 hp 2 8
R 4999 cc 550 hp 2 8
SVR 4999 cc 575 hp 2 8

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

2.0 8AT F-TYPE (300) 2.0 8AT F-TYPE R-DYNAMIC (300) 3.0 6MT F-TYPE (340) 3.0 8AT F-TYPE (340) 3.0 6MT F-TYPE (380) 3.0 8AT F-TYPE (380) 3.0 8AT F-TYPE AWD (380) 3.0 8AT F-TYPE (400) 3.0 8AT F-TYPE AWD (400) 5.0 8AT F-TYPE R AWD (550) 5.0 8AT F-TYPE SVR AWD (575) P300 P340 P340 P380 P380 P380 P400 P400 R SVR
2.0 8AT F-TYPE (300) 76 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1997
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 300
Torque, Nm 400
RPM at max torque 1500-4000
Engine 2.0 Si4
RPM at max power 5500
Turbo +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1577
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Brake system

The front brakes Disk
Rear brakes Disk

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.8
Fuel consumption (urban), l. 100 km 6.2
Fuel consumption (combined), l. 100 km 7.2
Acceleration (0-100 km/h), s 5.7
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Cruise Control +
Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 18
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

Xenon headlights +
Light sensor +
Rear LED lights +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
2.0 8AT F-TYPE R-DYNAMIC (300) 77 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1997
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 300
Torque, Nm 400
RPM at max torque 1500-4000
Engine 2.0 Si4
RPM at max power 5500
Turbo +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1577
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Brake system

The front brakes Disk
Rear brakes Disk

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.8
Fuel consumption (urban), l. 100 km 6.2
Fuel consumption (combined), l. 100 km 7.2
Acceleration (0-100 km/h), s 5.7
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Cruise Control +
Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 19
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

LED headlights +
Light sensor +
Rear LED lights +
LED lights daylight +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
3.0 6MT F-TYPE (340) 76 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 340
Torque, Nm 450
RPM at max torque 3500-5000
Engine 3.0i Si6
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Brake system

The front brakes Disk
Rear brakes Disk

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13.5
Fuel consumption (urban), l. 100 km 7.6
Fuel consumption (combined), l. 100 km 9.8
Acceleration (0-100 km/h), s 5.7
The maximum speed, km / h. 260
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Rear
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 18
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

Xenon headlights +
Light sensor +
Rear LED lights +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
3.0 8AT F-TYPE (340) 76 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 340
Torque, Nm 450
RPM at max torque 3500-5000
Engine 3.0i Si6
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1577
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 11.7
Fuel consumption (urban), l. 100 km 6.5
Fuel consumption (combined), l. 100 km 8.4
Acceleration (0-100 km/h), s 5.3
The maximum speed, km / h. 260
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Cruise Control +
Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 18
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

Xenon headlights +
Light sensor +
Rear LED lights +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
3.0 6MT F-TYPE (380) 77 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 380
Torque, Nm 460
RPM at max torque 3500-5000
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1584
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2050
Width (without mirrors) mm 1923

Brake system

The front brakes Disk
Rear brakes Disk

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13.5
Fuel consumption (urban), l. 100 km 7.6
Fuel consumption (combined), l. 100 km 9.8
Acceleration (0-100 km/h), s 5.5
The maximum speed, km / h. 275
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Rear
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Cruise Control +
Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 19
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

Xenon headlights +
Light sensor +
Rear LED lights +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
3.0 8AT F-TYPE (380) 78 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 380
Torque, Nm 460
RPM at max torque 3500-5000
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1594
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2050
Width (without mirrors) mm 1923

Brake system

The front brakes Disk
Rear brakes Disk

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 12
Fuel consumption (urban), l. 100 km 6.6
Fuel consumption (combined), l. 100 km 8.6
Acceleration (0-100 km/h), s 4.9
The maximum speed, km / h. 275
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Cruise Control +
Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 19
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

Xenon headlights +
Light sensor +
Rear LED lights +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
3.0 8AT F-TYPE AWD (380) 78 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 380
Torque, Nm 460
RPM at max torque 3500-5000
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1674
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2150
Width (without mirrors) mm 1923

Brake system

The front brakes Disk
Rear brakes Disk

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 12.4
Fuel consumption (urban), l. 100 km 6.9
Fuel consumption (combined), l. 100 km 8.9
Acceleration (0-100 km/h), s 5.1
The maximum speed, km / h. 275
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Cruise Control +
Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 19
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

Xenon headlights +
Light sensor +
Rear LED lights +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
3.0 8AT F-TYPE (400) 77 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 400
Torque, Nm 460
RPM at max torque 3500-5500
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ133
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1585
Rear track, mm 1627
Kerb weight, kg 1594
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2050
Width (without mirrors) mm 1923

Brake system

The front brakes Disk
Rear brakes Disk

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 12
Fuel consumption (urban), l. 100 km 6.6
Fuel consumption (combined), l. 100 km 8.6
Acceleration (0-100 km/h), s 4.9
The maximum speed, km / h. 275

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Cruise Control +
Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 19
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

Xenon headlights +
Light sensor +
Rear LED lights +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
3.0 8AT F-TYPE AWD (400) 77 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 400
Torque, Nm 460
RPM at max torque 3500-5500
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ133
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1585
Rear track, mm 1627
Kerb weight, kg 1674
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2150
Width (without mirrors) mm 1923

Brake system

The front brakes Disk
Rear brakes Disk

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 12.4
Fuel consumption (urban), l. 100 km 6.9
Fuel consumption (combined), l. 100 km 8.9
Acceleration (0-100 km/h), s 5.1
The maximum speed, km / h. 275

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Comfort

Cruise Control +
Tyre pressure monitoring +
Start / Stop button for starting and stopping the engine +

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +

Wheels

Disc diameter 19
Rim type Alloy

Cabin climate and noise insulation

Climate control +

Glass, mirrors and sunroof

The rain sensor +
Heated side mirrors +

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +
USB +

Headlights and lighting

Xenon headlights +
Light sensor +
Rear LED lights +

Seats

Power front seats +
Sports seats +

Visibility and parking

Rear Parking Sensors +

Exterior

Rear spoiler +

Security

Electronic systems

Anti-lock braking system (ABS) +
Electronic Brakeforce Distribution (EBD, EBV, REF, EBFD) +
The emergency braking (Brake Assist) +
Vehicle Stability Control (ESP, DSC, ESC, VSC) +
Electronic Brake Assist EPB (Elecrtic Parking Brake) +
The recognition of driver fatigue +
Lane Assist +

Anti-theft systems

Alarm +
alarm +
Central locking with remote control +

Airbags

Driver's airbag +
Passenger Airbag +
Side airbags +
Curtain airbags +
5.0 8AT F-TYPE R AWD (550) 51 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 4999
Cylinders location V-shaped
Number of cylinders 8
Valves 32
Power, hp 550
Torque, Nm 680
Engine 5.0i Supercharged
Engine code AJ133
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1585
Rear track, mm 1627
Kerb weight, kg 1745
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2150
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 16.2
Fuel consumption (urban), l. 100 km 8.5
Fuel consumption (combined), l. 100 km 11.3
Acceleration (0-100 km/h), s 4.1
The maximum speed, km / h. 300
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Interior

Leather interior +
Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +
Aluminum pedals +

Wheels

Disc diameter 20
Rim type Alloy

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +

Headlights and lighting

Xenon headlights +

Seats

Power front seats +
Sports seats +
Memory seat adjustment +

Exterior

Rear spoiler +
5.0 8AT F-TYPE SVR AWD (575) 53 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 4999
Cylinders location V-shaped
Number of cylinders 8
Valves 32
Power, hp 575
Torque, Nm 700
RPM at max torque 3500-5000
Engine 5.0 V8 Kompressor
RPM at max power 6000-6500
Engine code AJ133
Compressor +

Dimensions

Seats 2
Length mm 4475
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1585
Rear track, mm 1611
Kerb weight, kg 1720
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.3
Gross weight, kg 2150
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 16.2
Fuel consumption (urban), l. 100 km 8.5
Fuel consumption (combined), l. 100 km 11.3
Acceleration (0-100 km/h), s 3.7
The maximum speed, km / h. 322
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany

Equipment

Interior

Decoration Leather interior elements (leather steering wheel, gearshift lever, etc.) +
Aluminum pedals +
finishing seats suede +

Wheels

Disc diameter 20
Rim type Alloy

Multimedia and instruments

Navigation system +
Audio Meridian;
Touch Screen +
Bluetooth hands free +

Headlights and lighting

Xenon headlights +

Seats

Power front seats +
Sports seats +
Memory seat adjustment +

Exterior

Rear spoiler +
P300 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1997
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 300
Torque, Nm 400
RPM at max torque 1500-4000
Engine 2.0 Si4
RPM at max power 5500
Turbo +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 8.8
Fuel consumption (urban), l. 100 km 6.2
Fuel consumption (combined), l. 100 km 7.2
Acceleration (0-100 km/h), s 5.7
The maximum speed, km / h. 250
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
P340 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 340
Torque, Nm 450
RPM at max torque 3500-5000
Engine 3.0i Si6
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13.5
Fuel consumption (urban), l. 100 km 7.6
Fuel consumption (combined), l. 100 km 9.8
Acceleration (0-100 km/h), s 5.7
The maximum speed, km / h. 260
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Rear
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer ZF
Transmission country of origin Germany
P340 40 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 340
Torque, Nm 450
RPM at max torque 3500-5000
Engine 3.0i Si6
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 11.7
Fuel consumption (urban), l. 100 km 6.5
Fuel consumption (combined), l. 100 km 8.4
Acceleration (0-100 km/h), s 5.3
The maximum speed, km / h. 260
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
P380 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 380
Torque, Nm 460
RPM at max torque 3500-5000
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 13.5
Fuel consumption (urban), l. 100 km 7.6
Fuel consumption (combined), l. 100 km 9.8
Acceleration (0-100 km/h), s 5.5
The maximum speed, km / h. 275
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Rear
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer ZF
Transmission country of origin Germany
P380 40 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 380
Torque, Nm 460
RPM at max torque 3500-5000
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 12
Fuel consumption (urban), l. 100 km 6.6
Fuel consumption (combined), l. 100 km 8.6
Acceleration (0-100 km/h), s 4.9
The maximum speed, km / h. 275
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
P380 40 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 380
Torque, Nm 460
RPM at max torque 3500-5000
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ126
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 12.4
Fuel consumption (urban), l. 100 km 6.9
Fuel consumption (combined), l. 100 km 8.9
Acceleration (0-100 km/h), s 5.1
The maximum speed, km / h. 275
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
P400 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 400
Torque, Nm 460
RPM at max torque 3500-5500
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ133
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 12
Fuel consumption (urban), l. 100 km 6.6
Fuel consumption (combined), l. 100 km 8.6
Acceleration (0-100 km/h), s 4.9
The maximum speed, km / h. 275

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Rear
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
P400 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 2995
Cylinders location V-shaped
Number of cylinders 6
Valves 24
Power, hp 400
Torque, Nm 460
RPM at max torque 3500-5500
Engine 3.0i Supercharged
Compression 10.5
RPM at max power 6500
Engine code AJ133
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 12.4
Fuel consumption (urban), l. 100 km 6.9
Fuel consumption (combined), l. 100 km 8.9
Acceleration (0-100 km/h), s 5.1
The maximum speed, km / h. 275

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
R 37 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 4999
Cylinders location V-shaped
Number of cylinders 8
Valves 32
Power, hp 550
Torque, Nm 680
Engine 5.0i Supercharged
Engine code AJ133
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 16.2
Fuel consumption (urban), l. 100 km 8.5
Fuel consumption (combined), l. 100 km 11.3
Acceleration (0-100 km/h), s 4.1
The maximum speed, km / h. 300
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
SVR 39 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 4999
Cylinders location V-shaped
Number of cylinders 8
Valves 32
Power, hp 575
Torque, Nm 700
RPM at max torque 3500-5000
Engine 5.0 V8 Kompressor
RPM at max power 6000-6500
Engine code AJ133
Compressor +

Dimensions

Seats 2
Length mm 4482
Width 2042
Height mm 1308
Wheelbase mm 2622
Front track, mm 1597
Rear track, mm 1649
Kerb weight, kg 1587
Trunk capacity, L 207
Fuel tank, l 70
Turning circle, m 10.7
Gross weight, kg 2000
Width (without mirrors) mm 1923

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 16.2
Fuel consumption (urban), l. 100 km 8.5
Fuel consumption (combined), l. 100 km 11.3
Acceleration (0-100 km/h), s 3.7
The maximum speed, km / h. 322
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 8
Drive Full
Transmission 8-speed automatic
Gearbox Machine
Transmission manufacturer ZF
Transmission country of origin Germany
FAQ

Jaguar F-Type questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Jaguar F-Type?

This page lists 21 trims for the Jaguar F-Type, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Jaguar F-Type?

The listed configurations show a power range of 300-575 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Jaguar F-Type?

The available specification data shows engine displacement from 1997-4999 cc across the trims listed on this page.

Which transmissions are listed for the Jaguar F-Type?

The transmission options currently shown for this model are: 8, 6. Open a trim section to see the full data for a specific configuration.

Are there photos for the Jaguar F-Type?

Yes. The gallery includes 26 photos for the Jaguar F-Type, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.

Explore more

Continue exploring Jaguar

Return to Jaguar models, browse the gallery, or compare the trims listed above.

All Jaguar models F-Type generations View photo gallery Read FAQ Compare trims
