Mercedes specifications

Mercedes G-Class (W463) specifications and photos

Mercedes G-Class (W463) specifications are shown with trim options, key technical data, and a model photo gallery. Compare 6 configurations by engine size, power, seating, and transmission. The gallery includes 50 photos for visual reference.

Years 2018
Body type suv
Trims 6
Photos 50
Mercedes G-Class (W463) 2018 suv
Overview

Mercedes G-Class (W463) at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Mercedes G-Class (W463) page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 286-585 hp and 2925-3982 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 286-585 hp
  • Engine displacement: 2925-3982 cc
  • Transmissions: 9
  • Seating: 5 seats
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 286-585 hp
Engine displacement 2925-3982 cc
Seating 5 seats
Transmissions 9
Trim / modification Engine Power Seats Transmission
G 500 3982 cc 422 hp 5 9
AMG G 63 3982 cc 585 hp 5 9
500 3982 cc 422 hp 5 9
63 AMG 3982 cc 585 hp 5 9
350d 2925 cc 286 hp 5 9
400d 2925 cc 330 hp 5 9

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

G 500 AMG G 63 500 63 AMG 350d 400d
G 500 47 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3982
Cylinders location V-shaped
Number of cylinders 8
Valves 32
Power, hp 422
Torque, Nm 610
RPM at max torque 2250-4750
Engine 4.0i
Compression 10.5
RPM at max power 5250-5500
Engine code M176 DE40 AL

Dimensions

Seats 5
Length mm 4825
Width 2187
Height mm 1969
Wheelbase mm 2890
Front track, mm 1638
Rear track, mm 1638
Kerb weight, kg 2595
Trunk capacity, L 487
Fuel tank, l 75
Turning circle, m 13.6
Ground clearance, mm 270
Gross weight, kg 3200
Width (without mirrors) mm 1931

Suspension

Type of front suspension Trailing arm and Panhard rod
Rear suspension Trailing arm and Panhard rod

Brake system

The front brakes Ventilated disc
Rear brakes Disk
Brake booster +

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 14.9
Fuel consumption (urban), l. 100 km 9.8
Fuel consumption (combined), l. 100 km 11.7
Acceleration (0-100 km/h), s 5.9
The maximum speed, km / h. 210
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Full
Transmission 9G-Tronic
Gearbox Machine
Transmission manufacturer Daimler AG
Transmission country of origin Germany

Equipment

Wheels

Disc diameter 18
Tires 265/60R18
AMG G 63 46 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3982
Cylinders location V-shaped
Number of cylinders 8
Valves 32
Power, hp 585
Torque, Nm 850
RPM at max torque 2500-3500
Engine 4.0i
RPM at max power 6000
Engine code M177 DE40 AL

Dimensions

Seats 5
Length mm 4825
Width 2187
Height mm 1969
Wheelbase mm 2890
Front track, mm 1638
Rear track, mm 1638
Kerb weight, kg 2550
Trunk capacity, L 487
Fuel tank, l 75
Turning circle, m 13.6
Ground clearance, mm 270
Gross weight, kg 3200
Width (without mirrors) mm 1931

Suspension

Type of front suspension Trailing arm and Panhard rod
Rear suspension Trailing arm and Panhard rod

Brake system

The front brakes Ventilated disc
Rear brakes Disk
Brake booster +

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 16.5
Fuel consumption (urban), l. 100 km 11.5
Fuel consumption (combined), l. 100 km 13
Acceleration (0-100 km/h), s 4.5
The maximum speed, km / h. 220
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Full
Transmission 9G-Tronic
Gearbox Machine
Transmission manufacturer Daimler AG
Transmission country of origin Germany

Equipment

Wheels

Disc diameter 20
Tires 275/50R20
500 37 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3982
Cylinders location V-shaped
Number of cylinders 8
Valves 32
Power, hp 422
Torque, Nm 610
RPM at max torque 2250-4750
Engine 4.0i
Compression 10.5
RPM at max power 5250-5500
Engine code M176 DE40 AL

Dimensions

Seats 5
Length mm 4825
Width 2187
Height mm 1969
Wheelbase mm 2890
Front track, mm 1638
Rear track, mm 1638
Fuel tank, l 75
Turning circle, m 13.6
Ground clearance, mm 270
Width (without mirrors) mm 1931

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 14.9
Fuel consumption (urban), l. 100 km 9.8
Fuel consumption (combined), l. 100 km 11.7
Acceleration (0-100 km/h), s 5.9
The maximum speed, km / h. 210
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Full
Transmission 9G-Tronic
Gearbox Machine
Transmission manufacturer Daimler AG
Transmission country of origin Germany
63 AMG 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 3982
Cylinders location V-shaped
Number of cylinders 8
Valves 32
Power, hp 585
Torque, Nm 850
RPM at max torque 2500-3500
Engine 4.0i
RPM at max power 6000
Engine code M177 DE40 AL

Dimensions

Seats 5
Length mm 4825
Width 2187
Height mm 1969
Wheelbase mm 2890
Front track, mm 1638
Rear track, mm 1638
Fuel tank, l 75
Turning circle, m 13.6
Ground clearance, mm 270
Width (without mirrors) mm 1931

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 16.5
Fuel consumption (urban), l. 100 km 11.5
Fuel consumption (combined), l. 100 km 13
Acceleration (0-100 km/h), s 4.5
The maximum speed, km / h. 220
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Full
Transmission 9G-Tronic
Gearbox Machine
Transmission manufacturer Daimler AG
Transmission country of origin Germany
350d 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2925
Cylinders location In-line
Number of cylinders 6
Valves 24
Power, hp 286
Torque, Nm 600
RPM at max torque 1200–3200
Engine 2.9d
Compression 15,5
RPM at max power 3400–4600
Turbo +
Engine code OM656 D29 R SCR

Dimensions

Seats 5
Length mm 4825
Width 2187
Height mm 1969
Wheelbase mm 2890
Front track, mm 1638
Rear track, mm 1638
Fuel tank, l 75
Turning circle, m 13.6
Ground clearance, mm 270
Width (without mirrors) mm 1931

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 11
Fuel consumption (urban), l. 100 km 9.2
Fuel consumption (combined), l. 100 km 9.8
Acceleration (0-100 km/h), s 7.4
The maximum speed, km / h. 199
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Full
Transmission 9G-Tronic
Gearbox Machine
Transmission manufacturer Daimler AG
Transmission country of origin Germany
400d 38 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2925
Cylinders location In-line
Number of cylinders 6
Valves 24
Power, hp 330
Torque, Nm 700
RPM at max torque 1200-3000
Engine 2.9d
Compression 15.5
RPM at max power 3600-4000
Turbo +
Engine code OM656

Dimensions

Seats 5
Length mm 4825
Width 2187
Height mm 1969
Wheelbase mm 2890
Front track, mm 1638
Rear track, mm 1638
Fuel tank, l 75
Turning circle, m 13.6
Ground clearance, mm 270
Width (without mirrors) mm 1931

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 10.8
Fuel consumption (urban), l. 100 km 8.9
Fuel consumption (combined), l. 100 km 9.6
Acceleration (0-100 km/h), s 6.4
The maximum speed, km / h. 210
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Full
Transmission 9G-Tronic
Gearbox Machine
Transmission manufacturer Daimler AG
Transmission country of origin Germany
FAQ

Mercedes G-Class (W463) questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Mercedes G-Class (W463)?

This page lists 6 trims for the Mercedes G-Class (W463), with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Mercedes G-Class (W463)?

The listed configurations show a power range of 286-585 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Mercedes G-Class (W463)?

The available specification data shows engine displacement from 2925-3982 cc across the trims listed on this page.

Which transmissions are listed for the Mercedes G-Class (W463)?

The transmission options currently shown for this model are: 9. Open a trim section to see the full data for a specific configuration.

Are there photos for the Mercedes G-Class (W463)?

Yes. The gallery includes 50 photos for the Mercedes G-Class (W463), including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
