SsangYong specifications

SsangYong Rodius specifications and photos

SsangYong Rodius specifications are shown with trim options, key technical data, and a model photo gallery. Compare 6 configurations by engine size, power, seating, and transmission. The gallery includes 22 photos for visual reference.

Years 2018
Body type minivan
Trims 6
Photos 22
SsangYong Rodius 2018 minivan
Overview

SsangYong Rodius at a glance

Quick model context before comparing photos and trim-level specifications.

Use this SsangYong Rodius page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 155-178 hp and 1998-2157 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 155-178 hp
  • Engine displacement: 1998-2157 cc
  • Transmissions: 6, 5, 6-speed manual
  • Seating: 11 seats
Research hub

Photos, trims and specifications for SsangYong Rodius

This model page brings gallery images, trim comparison, and detailed technical data together for the 2018 generation.

Open photo gallery 22 images Compare trims 6 configurations View detailed specs 1998-2157 cc Explore related pages SsangYong and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 155-178 hp
Engine displacement 1998-2157 cc
Seating 11 seats
Transmissions 6, 5, 6-speed manual
Trim / modification Engine Power Seats Transmission
2.0 D (155 hp) 6-speed 1998 cc 155 hp 11 6
2.0 D (155 HP) 5 T-Tronic 1998 cc 155 hp 11 5
2.0 D (155 HP) 5 T-Tronic 4x4 1998 cc 155 hp 11 5
2.2 D (178 hp) 6-speed manual 2157 cc 178 hp 11 6-speed manual
2.2 D (178 HP) 7G-Tronic 2157 cc 178 hp 11 7
2.2 D (178 HP) 7G-Tronic 4x4 2157 cc 178 hp 11 7

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

2.0 D (155 hp) 6-speed 2.0 D (155 HP) 5 T-Tronic 2.0 D (155 HP) 5 T-Tronic 4x4 2.2 D (178 hp) 6-speed manual 2.2 D (178 HP) 7G-Tronic 2.2 D (178 HP) 7G-Tronic 4x4
2.0 D (155 hp) 6-speed 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 155
Torque, Nm 360
RPM at max torque 1500-2800
Engine 2.0 D
Compression 16.5
RPM at max power 4000
Turbo +

Dimensions

Seats 11
Length mm 5130
Height mm 1815
Wheelbase mm 3000
Front track, mm 1610
Rear track, mm 1620
Kerb weight, kg 2085
Turning circle, m 11.4
Ground clearance, mm 182
Gross weight, kg 2820
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 10.3
Fuel consumption (urban), l. 100 km 6.8
Fuel consumption (combined), l. 100 km 8
The maximum speed, km / h. 180
The rate of toxicity Euro V

Transmission and drive

Number of gears 6
Drive Rear
Transmission 6-speed manual
Gearbox Mechanics
2.0 D (155 HP) 5 T-Tronic 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 155
Torque, Nm 360
RPM at max torque 1500-2800
Engine 2.0 D
Compression 16.5
RPM at max power 4000
Turbo +

Dimensions

Seats 11
Length mm 5130
Height mm 1815
Wheelbase mm 3000
Front track, mm 1610
Rear track, mm 1620
Kerb weight, kg 2085
Turning circle, m 11.4
Ground clearance, mm 182
Gross weight, kg 2820
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 10.4
Fuel consumption (urban), l. 100 km 7.1
Fuel consumption (combined), l. 100 km 8.3
The maximum speed, km / h. 181
The rate of toxicity Euro V

Transmission and drive

Automatic transmission +
Number of gears 5
Drive Rear
Transmission 5 T-Tronic
Gearbox Machine
Transmission manufacturer Mercedes license
Transmission country of origin Korea
2.0 D (155 HP) 5 T-Tronic 4x4 36 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 155
Torque, Nm 360
RPM at max torque 1500-2800
Engine 2.0 D
Compression 16.5
RPM at max power 4000
Turbo +

Dimensions

Seats 11
Length mm 5130
Height mm 1815
Wheelbase mm 3000
Front track, mm 1610
Rear track, mm 1620
Kerb weight, kg 2085
Turning circle, m 11.4
Ground clearance, mm 182
Gross weight, kg 2820
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 10.8
Fuel consumption (urban), l. 100 km 7.2
Fuel consumption (combined), l. 100 km 8.5
The maximum speed, km / h. 181
The rate of toxicity Euro V

Transmission and drive

Automatic transmission +
Number of gears 5
Drive Full
Transmission 5 T-Tronic
Gearbox Machine
Transmission manufacturer Mercedes license
Transmission country of origin Korea
2.2 D (178 hp) 6-speed manual 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2157
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 178
Torque, Nm 407
RPM at max torque 1400-2800
Engine 2.2 D
RPM at max power 4000
Turbo +

Dimensions

Seats 11
Length mm 5130
Height mm 1815
Wheelbase mm 3000
Front track, mm 1610
Rear track, mm 1620
Kerb weight, kg 2085
Turning circle, m 11.4
Ground clearance, mm 182
Gross weight, kg 2820
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9.3
Fuel consumption (urban), l. 100 km 6.4
Fuel consumption (combined), l. 100 km 7.5
The maximum speed, km / h. 187
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Rear
Transmission 6-speed manual
Gearbox Mechanics
2.2 D (178 HP) 7G-Tronic 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2157
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 178
Torque, Nm 407
RPM at max torque 1400-2800
Engine 2.2 D
RPM at max power 4000
Turbo +

Dimensions

Seats 11
Length mm 5130
Height mm 1815
Wheelbase mm 3000
Front track, mm 1610
Rear track, mm 1620
Kerb weight, kg 2085
Turning circle, m 11.4
Ground clearance, mm 182
Gross weight, kg 2820
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9.9
Fuel consumption (urban), l. 100 km 6.5
Fuel consumption (combined), l. 100 km 7.8
The maximum speed, km / h. 187
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Rear
Transmission 7G-Tronic
Gearbox Machine
Transmission manufacturer Mercedes
Transmission country of origin Germany
2.2 D (178 HP) 7G-Tronic 4x4 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 2157
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 178
Torque, Nm 407
RPM at max torque 1400-2800
Engine 2.2 D
RPM at max power 4000
Turbo +

Dimensions

Seats 11
Length mm 5130
Height mm 1815
Wheelbase mm 3000
Front track, mm 1610
Rear track, mm 1620
Kerb weight, kg 2085
Turning circle, m 11.4
Ground clearance, mm 182
Gross weight, kg 2820
Width (without mirrors) mm 1915

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 10.1
Fuel consumption (urban), l. 100 km 6.7
Fuel consumption (combined), l. 100 km 8
The maximum speed, km / h. 187
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Full
Transmission 7G-Tronic
Gearbox Machine
Transmission manufacturer Mercedes
Transmission country of origin Germany
FAQ

SsangYong Rodius questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the SsangYong Rodius?

This page lists 6 trims for the SsangYong Rodius, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the SsangYong Rodius?

The listed configurations show a power range of 155-178 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the SsangYong Rodius?

The available specification data shows engine displacement from 1998-2157 cc across the trims listed on this page.

Which transmissions are listed for the SsangYong Rodius?

The transmission options currently shown for this model are: 6, 5, 6-speed manual. Open a trim section to see the full data for a specific configuration.

Are there photos for the SsangYong Rodius?

Yes. The gallery includes 22 photos for the SsangYong Rodius, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
