Zotye specifications

Zotye SR7 specifications and photos

Zotye SR7 specifications are shown with trim options, key technical data, and a model photo gallery. Compare 4 configurations by engine size, power, seating, and transmission. The gallery includes 4 photos for visual reference.

Years 2016
Body type suv
Trims 4
Photos 4
Zotye SR7 2016 SUV
Overview

Zotye SR7 at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Zotye SR7 page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 150 hp and 1499 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 150 hp
  • Engine displacement: 1499 cc
  • Transmissions: 5, 5-speed manual
  • Seating: 5 seats
Research hub

Photos, trims and specifications for Zotye SR7

This model page brings gallery images, trim comparison, and detailed technical data together for the 2016 generation.

Open photo gallery 4 images Compare trims 4 configurations View detailed specs 1499 cc Explore related pages Zotye and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 150 hp
Engine displacement 1499 cc
Seating 5 seats
Transmissions 5, 5-speed manual
Trim / modification Engine Power Seats Transmission
1.5 MT 1499 cc 150 hp 5 5
1.5 AT 1499 cc 150 hp 5 -
1.5 MIVEC (150 h.p.) 5-speed manual 1499 cc 150 hp 5 5-speed manual
1.5 MIVEC (150 HP) CVT 1499 cc 150 hp 5 -

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

1.5 MT 1.5 AT 1.5 MIVEC (150 h.p.) 5-speed manual 1.5 MIVEC (150 HP) CVT
1.5 MT 37 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1499
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 150
Torque, Nm 195
RPM at max torque 4200-4400
Engine 1.5 MIVEC
Compression 9.5
RPM at max power 6000
Turbo +
Engine code 4A91T

Dimensions

Seats 5
Length mm 4510
Width 1835
Height mm 1610
Wheelbase mm 2680
Front track, mm 1565
Rear track, mm 1563
Kerb weight, kg 1440
Trunk capacity, L 480
Fuel tank, l 55
Ground clearance, mm 180
Gross weight, kg 1825

Suspension

Type of front suspension MacPherson
Rear suspension Torsion beam

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Performance and fuel consumption

The rate of toxicity Euro V

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission manufacturer Zotye
Transmission country of origin China
1.5 AT 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1499
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 150
Torque, Nm 195
RPM at max torque 4200-4400
Engine 1.5 MIVEC
Compression 9.5
RPM at max power 6000
Turbo +
Engine code 4A91T

Dimensions

Seats 5
Length mm 4510
Width 1835
Height mm 1610
Wheelbase mm 2680
Front track, mm 1565
Rear track, mm 1563
Kerb weight, kg 1470
Trunk capacity, L 480
Fuel tank, l 55
Ground clearance, mm 180
Gross weight, kg 1853

Suspension

Type of front suspension MacPherson
Rear suspension Torsion beam

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Performance and fuel consumption

The rate of toxicity Euro V

Transmission and drive

Automatic transmission +
Drive Front
Transmission CVT
Gearbox Variable speed drive
1.5 MIVEC (150 h.p.) 5-speed manual 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1499
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 150
Torque, Nm 195
RPM at max torque 4200-4400
Engine 1.5 MIVEC
Compression 9.5
RPM at max power 6000
Turbo +
Engine code 4A91T

Dimensions

Seats 5
Length mm 4510
Width 1835
Height mm 1610
Wheelbase mm 2680
Front track, mm 1565
Rear track, mm 1563
Kerb weight, kg 1440
Trunk capacity, L 480
Fuel tank, l 55
Ground clearance, mm 180
Gross weight, kg 1825

Performance and fuel consumption

The rate of toxicity Euro V

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission manufacturer Zotye
Transmission country of origin China
1.5 MIVEC (150 HP) CVT 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1499
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 150
Torque, Nm 195
RPM at max torque 4200-4400
Engine 1.5 MIVEC
Compression 9.5
RPM at max power 6000
Turbo +
Engine code 4A91T

Dimensions

Seats 5
Length mm 4510
Width 1835
Height mm 1610
Wheelbase mm 2680
Front track, mm 1565
Rear track, mm 1563
Kerb weight, kg 1440
Trunk capacity, L 480
Fuel tank, l 55
Ground clearance, mm 180
Gross weight, kg 1825

Performance and fuel consumption

The rate of toxicity Euro V

Transmission and drive

Automatic transmission +
Drive Front
Transmission CVT
Gearbox Variable speed drive
FAQ

Zotye SR7 questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Zotye SR7?

This page lists 4 trims for the Zotye SR7, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Zotye SR7?

The listed configurations show a power range of 150 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Zotye SR7?

The available specification data shows engine displacement from 1499 cc across the trims listed on this page.

Which transmissions are listed for the Zotye SR7?

The transmission options currently shown for this model are: 5, 5-speed manual. Open a trim section to see the full data for a specific configuration.

Are there photos for the Zotye SR7?

Yes. The gallery includes 4 photos for the Zotye SR7, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
