Chevrolet Equinox specifications and photos

Chevrolet Equinox specifications are shown with trim options, key technical data, and a model photo gallery. Compare 8 configurations by engine size, power, seating, and transmission. The gallery includes 21 photos for visual reference.

Years 2017
Body type suv
Trims 8
Photos 21
Interior of Chevrolet Equinox 2017
Overview

Chevrolet Equinox at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Chevrolet Equinox page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 137-260 hp and 1500-1998 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 137-260 hp
  • Engine displacement: 1500-1998 cc
  • Transmissions: 6, 9-speed automatic, 9
  • Seating: 5 seats
Research hub

Photos, trims and specifications for Chevrolet Equinox

This model page brings gallery images, trim comparison, and detailed technical data together for the 2017 generation.

Open photo gallery 21 images Compare trims 8 configurations View detailed specs 1500-1998 cc Explore related pages Chevrolet and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 137-260 hp
Engine displacement 1500-1998 cc
Seating 5 seats
Transmissions 6, 9-speed automatic, 9
Trim / modification Engine Power Seats Transmission
1.5 AT 1500 cc 170 hp 5 6
1.5 AT AWD 1500 cc 170 hp 5 6
1.5i (170 HP) 6-car Hydra-Matic 1500 cc 170 hp 5 6
1.5i (170 HP) 6-car Hydra-Matic 4x4 1500 cc 170 hp 5 6
2.0i (260 hp) 9-speed automatic 1998 cc 260 hp 5 9-speed automatic
2.0i (260 hp) 9-speed 4x4 1998 cc 260 hp 5 9
1.6d (137 h.p.) 6-car Hydra-Matic 1598 cc 137 hp 5 6
1.6d (137 hp) 6-car Hydra-Matic 4x4 1598 cc 137 hp 5 6

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

1.5 AT 1.5 AT AWD 1.5i (170 HP) 6-car Hydra-Matic 1.5i (170 HP) 6-car Hydra-Matic 4x4 2.0i (260 hp) 9-speed automatic 2.0i (260 hp) 9-speed 4x4 1.6d (137 h.p.) 6-car Hydra-Matic 1.6d (137 hp) 6-car Hydra-Matic 4x4
1.5 AT 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 170
Torque, Nm 275
RPM at max torque 2000-4000
Engine 1.5i
RPM at max power 5600
Turbo +
Engine code LYX

Dimensions

Seats 5
Length mm 4651
Width 1844
Height mm 1661
Wheelbase mm 2725
Front track, mm 1580
Rear track, mm 1580
Trunk capacity, L 847
Fuel tank, l 56
Turning circle, m 11.4

Suspension

Type of front suspension Independent, such as MacPherson
Rear suspension Independent, multi-link

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9
Fuel consumption (urban), l. 100 km 7.4
Fuel consumption (combined), l. 100 km 8.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-car Hydra-Matic
Gearbox Machine
Transmission manufacturer GM
1.5 AT AWD 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 170
Torque, Nm 275
RPM at max torque 2000-4000
Engine 1.5i
RPM at max power 5600
Turbo +
Engine code LYX

Dimensions

Seats 5
Length mm 4651
Width 1844
Height mm 1661
Wheelbase mm 2725
Front track, mm 1580
Rear track, mm 1580
Trunk capacity, L 847
Fuel tank, l 56
Turning circle, m 11.4

Suspension

Type of front suspension Independent, such as MacPherson
Rear suspension Independent, multi-link

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9.8
Fuel consumption (urban), l. 100 km 7.8
Fuel consumption (combined), l. 100 km 9

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-car Hydra-Matic
Gearbox Machine
Transmission manufacturer GM
1.5i (170 HP) 6-car Hydra-Matic 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 170
Torque, Nm 275
RPM at max torque 2000-4000
Engine 1.5i
RPM at max power 5600
Turbo +
Engine code LYX

Dimensions

Seats 5
Length mm 4651
Height mm 1661
Wheelbase mm 2725
Front track, mm 1580
Rear track, mm 1580
Kerb weight, kg 1485
Trunk capacity, L 847
Fuel tank, l 56
Turning circle, m 11.4
Width (without mirrors) mm 1844

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9
Fuel consumption (urban), l. 100 km 7.4
Fuel consumption (combined), l. 100 km 8.4

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-car Hydra-Matic
Gearbox Machine
Transmission manufacturer GM
1.5i (170 HP) 6-car Hydra-Matic 4x4 33 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1500
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 170
Torque, Nm 275
RPM at max torque 2000-4000
Engine 1.5i
RPM at max power 5600
Turbo +
Engine code LYX

Dimensions

Seats 5
Length mm 4651
Height mm 1661
Wheelbase mm 2725
Front track, mm 1580
Rear track, mm 1580
Kerb weight, kg 1485
Trunk capacity, L 847
Fuel tank, l 56
Turning circle, m 11.4
Width (without mirrors) mm 1844

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 9.8
Fuel consumption (urban), l. 100 km 7.8
Fuel consumption (combined), l. 100 km 9

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-car Hydra-Matic
Gearbox Machine
Transmission manufacturer GM
2.0i (260 hp) 9-speed automatic 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 260
Torque, Nm 352
RPM at max torque 2000
Engine 2.0i
Compression 9.2
RPM at max power 5300
Turbo +
Engine code LTG/LNF

Dimensions

Seats 5
Length mm 4651
Height mm 1661
Wheelbase mm 2725
Front track, mm 1580
Rear track, mm 1580
Kerb weight, kg 1485
Trunk capacity, L 847
Fuel tank, l 56
Turning circle, m 11.4
Width (without mirrors) mm 1844

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 10.5
Fuel consumption (urban), l. 100 km 8
Fuel consumption (combined), l. 100 km 9

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Front
Transmission 9-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
2.0i (260 hp) 9-speed 4x4 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1998
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 260
Torque, Nm 352
RPM at max torque 2000
Engine 2.0i
Compression 9.2
RPM at max power 5300
Turbo +
Engine code LTG/LNF

Dimensions

Seats 5
Length mm 4651
Height mm 1661
Wheelbase mm 2725
Front track, mm 1580
Rear track, mm 1580
Kerb weight, kg 1485
Trunk capacity, L 847
Fuel tank, l 56
Turning circle, m 11.4
Width (without mirrors) mm 1844

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 10.9
Fuel consumption (urban), l. 100 km 8.3
Fuel consumption (combined), l. 100 km 9.6

Transmission and drive

Automatic transmission +
Number of gears 9
Drive Full
Transmission 9-speed automatic
Gearbox Machine
Transmission manufacturer GM
Transmission country of origin USA
1.6d (137 h.p.) 6-car Hydra-Matic 28 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1598
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 137
Torque, Nm 325
Engine 1.6d
Turbo +
Engine code LH7

Dimensions

Seats 5
Length mm 4651
Height mm 1661
Wheelbase mm 2725
Front track, mm 1580
Rear track, mm 1580
Kerb weight, kg 1485
Trunk capacity, L 847
Fuel tank, l 56
Turning circle, m 11.4
Width (without mirrors) mm 1844

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Front
Transmission 6-car Hydra-Matic
Gearbox Machine
Transmission manufacturer GM
1.6d (137 hp) 6-car Hydra-Matic 4x4 28 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1598
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 137
Torque, Nm 325
Engine 1.6d
Turbo +
Engine code LH7

Dimensions

Seats 5
Length mm 4651
Height mm 1661
Wheelbase mm 2725
Front track, mm 1580
Rear track, mm 1580
Kerb weight, kg 1485
Trunk capacity, L 847
Fuel tank, l 56
Turning circle, m 11.4
Width (without mirrors) mm 1844

Transmission and drive

Automatic transmission +
Number of gears 6
Drive Full
Transmission 6-car Hydra-Matic
Gearbox Machine
Transmission manufacturer GM
FAQ

Chevrolet Equinox questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Chevrolet Equinox?

This page lists 8 trims for the Chevrolet Equinox, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Chevrolet Equinox?

The listed configurations show a power range of 137-260 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Chevrolet Equinox?

The available specification data shows engine displacement from 1500-1998 cc across the trims listed on this page.

Which transmissions are listed for the Chevrolet Equinox?

The transmission options currently shown for this model are: 6, 9-speed automatic, 9. Open a trim section to see the full data for a specific configuration.

Are there photos for the Chevrolet Equinox?

Yes. The gallery includes 21 photos for the Chevrolet Equinox, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
