Hyundai specifications

Hyundai i20 Active specifications and photos

Hyundai i20 Active specifications are shown with trim options, key technical data, and a model photo gallery. Compare 6 configurations by engine size, power, seating, and transmission. The gallery includes 8 photos for visual reference.

Years 2015 - 2018
Body type hatchback
Trims 6
Photos 8
Hyundai i20 Active 2015 hatchback
Overview

Hyundai i20 Active at a glance

Quick model context before comparing photos and trim-level specifications.

Use this Hyundai i20 Active page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 90-120 hp and 998-1396 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 90-120 hp
  • Engine displacement: 998-1396 cc
  • Transmissions: 5, 6, 6-speed manual
  • Seating: 5 seats
Research hub

Photos, trims and specifications for Hyundai i20 Active

This model page brings gallery images, trim comparison, and detailed technical data together for the 2015 generation.

Open photo gallery 8 images Compare trims 6 configurations View detailed specs 998-1396 cc Explore related pages Hyundai and similar models
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 90-120 hp
Engine displacement 998-1396 cc
Seating 5 seats
Transmissions 5, 6, 6-speed manual
Trim / modification Engine Power Seats Transmission
1.0 5MT 998 cc 100 hp 5 5
1.0 6MT 998 cc 120 hp 5 6
1.4d 6MT 1396 cc 90 hp 5 6
1.0 T-GDI (100 HP) 5-Mech 998 cc 100 hp 5 5
1.0 T-GDI (120 h.p.) 6-speed manual 998 cc 120 hp 5 6-speed manual
1.4 CRDI (90 hp) 6-speed manual 1396 cc 90 hp 5 6-speed manual

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

1.0 5MT 1.0 6MT 1.4d 6MT 1.0 T-GDI (100 HP) 5-Mech 1.0 T-GDI (120 h.p.) 6-speed manual 1.4 CRDI (90 hp) 6-speed manual
1.0 5MT 42 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 998
Cylinders location In-line
Number of cylinders 3
Valves 12
Power, hp 100
Torque, Nm 172
RPM at max torque 1500-4000
Engine 1.0 T-GDI
Compression 10.0
RPM at max power 4500
Turbo +
Engine code G3LC

Dimensions

Seats 5
Length mm 4065
Height mm 1474
Wheelbase mm 2570
Front track, mm 1511
Rear track, mm 1513
Kerb weight, kg 1160
Trunk capacity, L 326
Fuel tank, l 50
Gross weight, kg 1610
Width (without mirrors) mm 1734

Suspension

Type of front suspension Independent McPherson type with anti-roll bar
Rear suspension Semi-independent, torsion beam

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.9
Fuel consumption (urban), l. 100 km 4.1
Fuel consumption (combined), l. 100 km 4.8
Acceleration (0-100 km/h), s 10.9
The maximum speed, km / h. 176
The rate of toxicity Euro VI

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin Korea
1.0 6MT 42 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 998
Cylinders location In-line
Number of cylinders 3
Valves 12
Power, hp 120
Torque, Nm 172
RPM at max torque 1500-4000
Engine 1.0 T-GDI
Compression 10.0
RPM at max power 6000
Turbo +
Engine code G3LC

Dimensions

Seats 5
Length mm 4065
Height mm 1474
Wheelbase mm 2570
Front track, mm 1511
Rear track, mm 1513
Kerb weight, kg 1165
Trunk capacity, L 326
Fuel tank, l 50
Gross weight, kg 1650
Width (without mirrors) mm 1734

Suspension

Type of front suspension Independent McPherson type with anti-roll bar
Rear suspension Semi-independent, torsion beam

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 6.2
Fuel consumption (urban), l. 100 km 4.5
Fuel consumption (combined), l. 100 km 5.1
Acceleration (0-100 km/h), s 10.4
The maximum speed, km / h. 183
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.4d 6MT 42 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1396
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 90
Torque, Nm 240
RPM at max torque 1500-2500
Engine 1.4 CRDI
Compression 17.0
RPM at max power 4000
Turbo +
Engine code D4FC

Dimensions

Seats 5
Length mm 4065
Height mm 1474
Wheelbase mm 2570
Front track, mm 1511
Rear track, mm 1513
Kerb weight, kg 1250
Trunk capacity, L 326
Fuel tank, l 50
Gross weight, kg 1700
Width (without mirrors) mm 1734

Suspension

Type of front suspension Independent McPherson type with anti-roll bar
Rear suspension Semi-independent, torsion beam

Brake system

The front brakes Ventilated disc
Rear brakes Disk

Steering

Power steering Electric power

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.3
Fuel consumption (urban), l. 100 km 3.8
Fuel consumption (combined), l. 100 km 4.3
Acceleration (0-100 km/h), s 12.3
The maximum speed, km / h. 170
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.0 T-GDI (100 HP) 5-Mech 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 998
Cylinders location In-line
Number of cylinders 3
Valves 12
Power, hp 100
Torque, Nm 172
RPM at max torque 1500-4000
Engine 1.0 T-GDI
Compression 10.0
RPM at max power 4500
Turbo +
Engine code G3LC

Dimensions

Seats 5
Length mm 4065
Height mm 1474
Wheelbase mm 2570
Front track, mm 1511
Rear track, mm 1513
Trunk capacity, L 326
Fuel tank, l 50
Width (without mirrors) mm 1734

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.9
Fuel consumption (urban), l. 100 km 4.1
Fuel consumption (combined), l. 100 km 4.8
Acceleration (0-100 km/h), s 10.9
The maximum speed, km / h. 176
The rate of toxicity Euro VI

Transmission and drive

Number of gears 5
Drive Front
Transmission 5-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin Korea
1.0 T-GDI (120 h.p.) 6-speed manual 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 998
Cylinders location In-line
Number of cylinders 3
Valves 12
Power, hp 120
Torque, Nm 172
RPM at max torque 1500-4000
Engine 1.0 T-GDI
Compression 10.0
RPM at max power 6000
Turbo +
Engine code G3LC

Dimensions

Seats 5
Length mm 4065
Height mm 1474
Wheelbase mm 2570
Front track, mm 1511
Rear track, mm 1513
Trunk capacity, L 326
Fuel tank, l 50
Width (without mirrors) mm 1734

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 6.2
Fuel consumption (urban), l. 100 km 4.5
Fuel consumption (combined), l. 100 km 5.1
Acceleration (0-100 km/h), s 10.4
The maximum speed, km / h. 183
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
1.4 CRDI (90 hp) 6-speed manual 35 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1396
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 90
Torque, Nm 240
RPM at max torque 1500-2500
Engine 1.4 CRDI
Compression 17.0
RPM at max power 4000
Turbo +
Engine code D4FC

Dimensions

Seats 5
Length mm 4065
Height mm 1474
Wheelbase mm 2570
Front track, mm 1511
Rear track, mm 1513
Trunk capacity, L 326
Fuel tank, l 50
Width (without mirrors) mm 1734

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.3
Fuel consumption (urban), l. 100 km 3.8
Fuel consumption (combined), l. 100 km 4.3
Acceleration (0-100 km/h), s 12.3
The maximum speed, km / h. 170
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Hyundai
Transmission country of origin South Korea
FAQ

Hyundai i20 Active questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the Hyundai i20 Active?

This page lists 6 trims for the Hyundai i20 Active, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the Hyundai i20 Active?

The listed configurations show a power range of 90-120 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the Hyundai i20 Active?

The available specification data shows engine displacement from 998-1396 cc across the trims listed on this page.

Which transmissions are listed for the Hyundai i20 Active?

The transmission options currently shown for this model are: 5, 6, 6-speed manual. Open a trim section to see the full data for a specific configuration.

Are there photos for the Hyundai i20 Active?

Yes. The gallery includes 8 photos for the Hyundai i20 Active, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
