KIA Carens specifications and photos

KIA Carens specifications are shown with trim options, key technical data, and a model photo gallery. Compare 5 configurations by engine size, power, seating, and transmission. The gallery includes 24 photos for visual reference.

Years 2016
Body type minivan
Trims 5
Photos 24
KIA Carens 2016 minivan
Overview

KIA Carens at a glance

Quick model context before comparing photos and trim-level specifications.

Use this KIA Carens page as a compact reference for photos, trim comparison, and detailed technical specifications. The current data covers 115-141 hp and 1591-1685 cc engine displacement. For exact values, open a trim section because specifications can differ between configurations.

  • Power: 115-141 hp
  • Engine displacement: 1591-1685 cc
  • Transmissions: 6, 6-speed manual, 7
  • Seating: 5 seats
Configurations

Trims and key specifications

Use this table to compare the main differences between available configurations.

Power 115-141 hp
Engine displacement 1591-1685 cc
Seating 5 seats
Transmissions 6, 6-speed manual, 7
Trim / modification Engine Power Seats Transmission
1.7 MT 1685 cc 141 hp 5 6
1.6 GDI (135 hp) 6-speed manual 1591 cc 135 hp 5/7 6-speed manual
1.7 CRDi (115 h.p.) 6-speed manual 1685 cc 115 hp 5/7 6-speed manual
1.7 CRDI (141 HP) 6-speed manual 1685 cc 141 hp 5/7 6-speed manual
1.7 CRDI (141 hp) 7-DCT 1685 cc 141 hp 5/7 7

Specifications can vary by market, model year, and equipment package. Use the trim sections below to review the full data for each configuration.

Detailed specs

Specifications by trim

Choose a configuration below to open full technical data grouped by category.

1.7 MT 1.6 GDI (135 hp) 6-speed manual 1.7 CRDi (115 h.p.) 6-speed manual 1.7 CRDI (141 HP) 6-speed manual 1.7 CRDI (141 hp) 7-DCT
1.7 MT 34 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1685
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 141
Torque, Nm 340
RPM at max torque 1750-2500
Engine 1.7 CRDI
Compression 15.7
RPM at max power 4000
Turbo +
Engine code D4FD

Dimensions

Seats 5
Length mm 4525
Width 1805
Height mm 1610
Wheelbase mm 2750
Kerb weight, kg 1545
Trunk capacity, L 495

Suspension

Type of front suspension MacPherson
Rear suspension Torsion beam

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.1
Fuel consumption (urban), l. 100 km 4.2
Fuel consumption (combined), l. 100 km 4.5
Acceleration (0-100 km/h), s 10
The maximum speed, km / h. 193
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Kia Motors
1.6 GDI (135 hp) 6-speed manual 31 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Gasoline
Displacement, cc 1591
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 135
Torque, Nm 165
RPM at max torque 4850
Engine 1.6 GDI
Compression 11.0
RPM at max power 6300
Engine code G4FD

Dimensions

Seats 5/7
Length mm 4525
Width 1805
Height mm 1610
Wheelbase mm 2750
Kerb weight, kg 1545
Trunk capacity, L 495

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 7.8
Fuel consumption (urban), l. 100 km 5.2
Fuel consumption (combined), l. 100 km 6.2
Acceleration (0-100 km/h), s 10.9
The maximum speed, km / h. 185
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Kia Motors
1.7 CRDi (115 h.p.) 6-speed manual 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1685
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 115
Torque, Nm 260
RPM at max torque 1250-2750
Engine 1.7 CRDi
Compression 17.1
RPM at max power 4000
Turbo +
Engine code D4FD

Dimensions

Seats 5/7
Length mm 4525
Width 1805
Height mm 1610
Wheelbase mm 2750
Kerb weight, kg 1545
Trunk capacity, L 495

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.1
Fuel consumption (urban), l. 100 km 4.2
Fuel consumption (combined), l. 100 km 4.5
Acceleration (0-100 km/h), s 12.7
The maximum speed, km / h. 177
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Kia Motors
1.7 CRDI (141 HP) 6-speed manual 32 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1685
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 141
Torque, Nm 340
RPM at max torque 1750-2500
Engine 1.7 CRDI
Compression 15.7
RPM at max power 4000
Turbo +
Engine code D4FD

Dimensions

Seats 5/7
Length mm 4525
Width 1805
Height mm 1610
Wheelbase mm 2750
Kerb weight, kg 1545
Trunk capacity, L 495

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.1
Fuel consumption (urban), l. 100 km 4.2
Fuel consumption (combined), l. 100 km 4.5
Acceleration (0-100 km/h), s 10
The maximum speed, km / h. 193
The rate of toxicity Euro VI

Transmission and drive

Number of gears 6
Drive Front
Transmission 6-speed manual
Gearbox Mechanics
Transmission manufacturer Kia Motors
1.7 CRDI (141 hp) 7-DCT 34 specifications

Specifications

Engine

Type of engine ICE
Type of fuel Diesel
Displacement, cc 1685
Cylinders location In-line
Number of cylinders 4
Valves 16
Power, hp 141
Torque, Nm 340
RPM at max torque 1750-2500
Engine 1.7 CRDI
Compression 15.7
RPM at max power 4000
Turbo +
Engine code D4FD

Dimensions

Seats 5/7
Length mm 4525
Width 1805
Height mm 1610
Wheelbase mm 2750
Kerb weight, kg 1545
Trunk capacity, L 495

Performance and fuel consumption

Fuel consumption (urban cycle), l. 100 km 5.3
Fuel consumption (urban), l. 100 km 4.5
Fuel consumption (combined), l. 100 km 4.8
Acceleration (0-100 km/h), s 10.9
The maximum speed, km / h. 188
The rate of toxicity Euro VI

Transmission and drive

Automatic transmission +
Number of gears 7
Drive Front
Transmission 7-speed dual-clutch
Gearbox 2 clutch robot
Transmission manufacturer Hyundai-KIA
Transmission country of origin South Korea
FAQ

KIA Carens questions

Short answers based on the specifications and photos available in this catalog.

How many trims are listed for the KIA Carens?

This page lists 5 trims for the KIA Carens, with key data shown in the comparison table and full specifications grouped below.

What is the power range for the KIA Carens?

The listed configurations show a power range of 115-141 hp. Exact output can vary by engine, transmission, market, and model year.

What engine displacement is shown for the KIA Carens?

The available specification data shows engine displacement from 1591-1685 cc across the trims listed on this page.

Which transmissions are listed for the KIA Carens?

The transmission options currently shown for this model are: 6, 6-speed manual, 7. Open a trim section to see the full data for a specific configuration.

Are there photos for the KIA Carens?

Yes. The gallery includes 24 photos for the KIA Carens, including exterior and interior views where available.

Why can specifications differ for the same model?

Automotive specifications can differ by market, production year, body style, trim package, and transmission. Use the trim selector and detailed specification sections to compare exact configurations.
